12 Genie HM/HC Series Overview Genie HM-HC Series-GigE Vision Camera
Genie HM/HC Series Sensor Overview
The sensor description below provides a specification table and response graphics. The graph describes the sensor
response to different wavelengths of light (excluding lens and light source characteristics). Visible light spans
wavelengths between about 390 - 780 nanometers. Wavelengths below 390 nm are termed ultra-violet while those
above 780 nm. are termed infra-red. The peak response is around 600 nanometers.
HM/HC Series Sensor Global Specifications
Item / Feature Specification
Imager Features Global Shutter, Exposure Control, Anti-Blooming
Sensor DALSA IA-G5 Area Array
Minimum Frame Rate (free-running) 0.1 fps (one frame every 10 seconds)
Maximum Frame Rate (free-running) Dependent on Genie HM/HC model (see Partial Scan—Window ROI)
Minimum Exposure 10μs when using reset exposure mode (triggered)
56μs when using synchronous exposure mode (free running)
Maximum Exposure ( 1 / frame rate ) - 10μs
Internal Trigger to Start of Exposure 100μs
Horizontal Line Time HM640/HC640 6.7μs
HM1024/HC1024 10.3μs
HM1400/HC1400 (8-bit) 14μs
HM1400/HC1499 (10-bit) 22.3μs
Pixel Size 7.4µm x 7.4µm
Pixel Format 8-bit all models
10-bit available only with HM1400/HM1400 XDR and HC1400
Bayer Mosaic Arrangement
(HC models only)
The HC color camera models have a Bayer filter applied to the
CMOS sensor to allow for color separation. Each individual
pixel is covered by either a red, green, or blue filter. The camera
outputs raw color data--no color interpolation is performed. Full
RGB images can be obtained by performing color interpolation
on the frame grabber or host PC.
Shutter Full frame electronic shutter
Gain Range 0dB to +12dB
