Dalsa Genie HM640 - C;Cs-Mount Nir and Uv Filter

120  Technical Specifications Genie HM-HC Series-GigE Vision Camera
C/CS-Mount NIR and UV Filter
Midwest Optical Systems has available a C-mount NIR/UV filter. This filter screws into the Genie camera before
mounting the lens. The figures below show the filter before mounting into the Genie, followed by the filter physical
specifications and pass spectrum. Contact Midwest Optical Systems directly for technical information and pricing.
Physical
Specifications:
Outside diameter: 25.4mm, 32 NS2A thread (c-mount thread)
Clear Aperture: 19.5mm
Thickness: 3.0 ±0.1mm
BP550 UV + NIR BLOCK/VISIBLE PASS
0.00
10.00
20.00
30.00
40.00
50.00
60.00
70.00
80.00
90.00
100.00
350 450 550 650 750 850 950 1050
Wavelength (nm)
Transmission (%)
For Information
contact:
Midwest Optical Systems
322 Woodwork Ln.
Palatine Il. 60067 USA
Tel: 847-359-3550
http://www.midwestopticalsystems.com/
