Genie HM-HC Series-GigE Vision Camera Genie HM/HC Series Overview  15
Genie HM/HC Series Effective Quantum Efficiency
The following quantum efficiency graph describes the fraction of photons at each wavelength that contribute charge
to the pixel.
Genie HM/HC Quantum Efficiency (%) Curve
0. 0 %
10.0%
20.0%
30.0%
40.0%
50.0%
60.0%
70.0%
400 500 600 700 80 0 900 1000
Wavelength ( nm)
Genie HM/HC Series Sensor Cosmetic Specifications
The following table lists the current cosmetic specifications for the DALSA sensor used in the Genie HM/HC series.
Blemish Specifications Maximum Number of Defects
Hot/Dead pixel defects 2
Single pixel defects 100 for HM series
25 for each individual color (R, G1, G2, B) for HC series
Clusters defects 0
Column defects 0
Row defects 0
Note: All of the sensor and camera cosmetic specifications are with factory flat-field correction turned on. There are
no pre-flat-field camera cosmetic specifications.
