Genie HM-HC Series-GigE Vision Camera Operational Reference 55
Input Controls via Sapera LT or GigE Vision Compliant Applications
Sapera
Genie Sapera parameters for Trigger Modes, Time Stamp and General Inputs:
TriggerDelayToIntegration = Delay in µs from trigger to exposure
TriggerEnable = {FALSE, TRUE}
TriggerSource = {Input 1 = 0, Input 2 = 1, Software = 2}
TriggerSoftware = {FALSE, TRUE}
FramesPerTrigger = Frame count 1 to 32767
TimestampResetSource = {Off = 0, Input 1 = 1, Input 2 = 2}
TimestampCounter = {Internal Clock = 0, Input 1 = 1, Input 2 = 2, End of Readout = 3}
TimestampReset = {FALSE, TRUE}
PolarityInput_x = {Active High = 0, Active Low = 1}
DebounceInput_x = debouncing period in µs (from 1 to 255 µs)
InputPinStatusInput_1 = {FALSE, TRUE}
InputPinStatusInput_2 = {FALSE, TRUE}
See "Accessing Features with Sapera++ LT" on page 76.
XML features for Trigger Modes, Time Stamp and General Inputs:
TriggerMode = {Off = 0, On = 1}
TriggerSelector = Select the type of trigger to control. FrameStart currently supported.
TriggerSoftware = Generates a software trigger to start the acquisition in any trigger mode
TriggerSource = External input or software signal as trigger source {Line2 = 1, Software = 2}
TriggerActivation = {LevelLow = 0, LevelHigh = 1, RisingEdge, FallingEdge, AnyEdge}
TriggerDelayAbs = Absolute delay to apply in us after reception of the trigger signal before
starting exposure
TriggerDelayRaw = Absolute delay to apply in us after reception of the trigger signal before
starting exposure
GevTimestampTickFrequency = 64-bit value indicating the number of timestamp clock ticks
in one second.
GevTimestampControlLatch = Latches the current timestamp value of the device.
GevTimestampControlReset = Resets the timestamp count of the device.
GevTimestampValue = Latched 64-bit value of the timestamp. Value must first be latched
using GevTimestampControlLatch.
CounterSelector = Select counter to configure. Currently only Timestamp is supported.
CounterEventSource = Select counter source as {Internal Clock = 0, Input 1 = 1, Input 2 = 2,
End of Readout = 3}
CounterLineSource = Source for the line to count.
CounterReset = Resets the selected Counter.
InputLineSelector = Index to general input {input1=0, input2=1}
InputLinePolarity = {Active High = 0, Active Low = 1}
InputLineDebouncingPeriod = debounce period in µs (from 1 to 255 µs)
InputLineValue = Read input line state {low=0, high=1}
LineStatus = Current logical state of signal at time of polling {FALSE, TRUE}
Line Mode = Indicate if the line is an input or an output.
