Spyder3 GigE Vision User’s Manual
DALSA 03-032-20027-02
81
Mnemonic Syntax Parameters
Description
set sync frequency
ssf
i
Set the frame rate to a value from
300Hz to 36000Hz (2k model) or
300Hz to 68000Hz (1k model). Value
rounded up/down as required.
set system gain
ssg
t i
Set the digital gain.
t = tap selection, either 1 to 2, or 0 for
all taps
i = Digital gain in a range from 0 to
65535. (4k limit is 12953.) The digital
video values are multiplied by this
number.
set sensitivity mode
ssm
i
Sets the camera’s sensitivity mode
where i is:
0 = Low sensitivity mode
1 = High sensitivity mode
2 = Tall pixel mode
set upper threshold
sut
i
The pixels equal to or greater than the
upper threshold are checked for and
reported in the end-of-line sequence in
a range from 0-4095.
set video mode
svm
i
Switch between normal video mode
and camera test patterns:
0: Normal video mode
1: Camera test pattern
2: Camera test pattern
update gain reference
ugr
Changes 0dB gain to equal the current
analog gain value set with the sag
command.
verify temperature
vt
Check the internal temperature of the
camera
verify voltage
vv
Check the camera’s input voltages and
return OK or fail
write FPN coefficients
wfc
i
Write all current FPN coefficients to
EEROM where i is:
1 = FPN coefficient set one
2 = FPN coefficient set two
3 = FPN coefficient set one
4 = FPN coefficient set two
write PRNU coeffs
wpc
i
Write all current PRNU coefficients to
EEROM where i is:
1 = PRNU coefficient set one
2 = PRNU coefficient set two
3 = PRNU coefficient set one
4 = PRNU coefficient set two
write user settings
wus
Write all of the user settings to EEROM.
