14
PART LIST OF STANDARD TYPE GEAR UNITS
Dana Incorporated IMM-0016EN - Installation and Maintenance Manual
4.6 D...0E... TYPES FOR 3 STAGED GEAR UNITS
NOTE:
Standard D...0E... type basic part diagram. Parts may differ for special applications.
1
2
3
4
5
6
7
8
9
9
10
11
12
Standard Part List
1Circlip
2Spacer
3Flange
4Bolt
5 Extruder Neck
6Bolt
7Seal
8Bearing
9Key
10 Hollow Shaft Output
11 Spacer
12 Seal
