MECHANICAL INSTALLATION
33Dana IncorporatedIMM-0016EN - Installation and Maintenance Manual
8.5 SHAFT TIGHTENING TORQUES
Use the following table for shaft tightening torques.
Table 6:
Type Bolt Tightining Torque [Nm]
D.072/073 M10 20
D.172/173 M10 20
D.272/273 M12 20
D.282/283 M16 40
D.372/373 M16 40
D.472/473 M16 40
D.572/573 M20 80
D.672/673 M20 80
D.772/773 M24 200
D.872/873 M24 200
D.972/973 M24 200
