MECHANICAL INSTALLATION

Dana Incorporated IMM-0016EN - Installation and Maintenance Manual

8.2 INSTALLING CUSTOMER SHAFT WITHOUT SHOULDER

Use anti-seize mounting paste available on your market. Use a brush to apply the paste.

Fasten the bold as shown below.

1 - Retaining Bolt

2 - Lock Washer

3 - Washer

4 - Circlip

5 - Hollow Shaft

6 - Customer Shaft
