7.3.20 22-** Application Functions
Par. No.
#
Parameter description Default value 4-set-up Change during
operation
Conver-
sion index
Type
22-0* Miscellaneous
22-00 External Interlock Delay 0 s All set-ups TRUE 0 Uint16
22-01 Power Filter Time 0.50 s 2 set-ups TRUE -2 Uint16
22-2* No-Flow Detection
22-20 Low Power Auto Set-up [0] Off All set-ups FALSE - Uint8
22-21 Low Power Detection [0] Disabled All set-ups TRUE - Uint8
22-22 Low Speed Detection [0] Disabled All set-ups TRUE - Uint8
22-23 No-Flow Function [0] Off All set-ups TRUE - Uint8
22-24 No-Flow Delay 10 s All set-ups TRUE 0 Uint16
22-26 Dry Pump Function [0] Off All set-ups TRUE - Uint8
22-27 Dry Pump Delay 10 s All set-ups TRUE 0 Uint16
22-3* No-Flow Power Tuning
22-30 No-Flow Power 0.00 kW All set-ups TRUE 1 Uint32
22-31 Power Correction Factor 100 % All set-ups TRUE 0 Uint16
22-32 Low Speed [RPM] SR All set-ups TRUE 67 Uint16
22-33 Low Speed [Hz] SR All set-ups TRUE -1 Uint16
22-34 Low Speed Power [kW] SR All set-ups TRUE 1 Uint32
22-35 Low Speed Power [HP] SR All set-ups TRUE -2 Uint32
22-36 High Speed [RPM] SR All set-ups TRUE 67 Uint16
22-37 High Speed [Hz] SR All set-ups TRUE -1 Uint16
22-38 High Speed Power [kW] SR All set-ups TRUE 1 Uint32
22-39 High Speed Power [HP] SR All set-ups TRUE -2 Uint32
22-4* Sleep Mode
22-40 Minimum Run Time 10 s All set-ups TRUE 0 Uint16
22-41 Minimum Sleep Time 10 s All set-ups TRUE 0 Uint16
22-42 Wake-up Speed [RPM] SR All set-ups TRUE 67 Uint16
22-43 Wake-up Speed [Hz] SR All set-ups TRUE -1 Uint16
22-44 Wake-up Ref./FB Difference 10 % All set-ups TRUE 0 Int8
22-45 Setpoint Boost 0 % All set-ups TRUE 0 Int8
22-46 Maximum Boost Time 60 s All set-ups TRUE 0 Uint16
22-5* End of Curve
22-50 End of Curve Function [0] Off All set-ups TRUE - Uint8
22-51 End of Curve Delay 10 s All set-ups TRUE 0 Uint16
22-6* Broken Belt Detection
22-60 Broken Belt Function [0] Off All set-ups TRUE - Uint8
22-61 Broken Belt Torque 10 % All set-ups TRUE 0 Uint8
22-62 Broken Belt Delay 10 s All set-ups TRUE 0 Uint16
22-7* Short Cycle Protection
22-75 Short Cycle Protection [0] Disabled All set-ups TRUE - Uint8
22-76 Interval between Starts
start_to_start_min_on_t
ime (P2277)
All set-ups TRUE 0 Uint16
22-77 Minimum Run Time 0 s All set-ups TRUE 0 Uint16
22-78 Minimum Run Time Override [0] Disabled All set-ups FALSE - Uint8
22-79 Minimum Run Time Override Value 0.000 ProcessCtrlUnit All set-ups TRUE -3 Int32
22-8* Flow Compensation
22-80 Flow Compensation [0] Disabled All set-ups TRUE - Uint8
22-81 Square-linear Curve Approximation 100 % All set-ups TRUE 0 Uint8
22-82 Work Point Calculation [0] Disabled All set-ups TRUE - Uint8
22-83 Speed at No-Flow [RPM] SR All set-ups TRUE 67 Uint16
22-84 Speed at No-Flow [Hz] SR All set-ups TRUE -1 Uint16
How to Programme the Frequ...
VLT
®
HVAC Drive Operating Instructions
MG.11.AD.02 - VLT
®
is a registered Danfoss trademark 117
