Data transfer from LCP to Frequency converter:
1.
Go to par. 0-50 LCP Copy
2. Press the [OK] key
3. Select “All from LCP”
4. Press the [OK] key
The parameter settings stored in the GLCP are now transferred
to the frequency converter indicated by the progress bar.
When 100% is reached, press [OK].
5.1.7 Initialisation to Default Settings
There are two ways to initialise the frequency converter to
default: Recommended initialisation and manual initialisation.
Please be aware that they have different impact according to
the below description.
Recommended initialisation (via par. 14-22 Operation Mode)
1. Select par. 14-22 Operation Mode
2. Press [OK]
3. Select “Initialisation” (for NLCP select “2”)
4. Press [OK]
5. Remove power to unit and wait for display to turn
off.
6. Reconnect power and the frequency converter is
reset. Note that first start-up takes a few more
seconds
7. Press [Reset]
Par. 14-22 Operation Mode initialises all except:
Par. 14-50 RFI Filter
Par. 8-30 Protocol
Par. 8-31 Address
Par. 8-32 Baud Rate
Par. 8-35 Minimum Response Delay
Par. 8-36 Max Response Delay
Par. 8-37 Maximum Inter-Char Delay
Par. 15-00 Operating Hours to par. 15-05 Over Volt's
Par. 15-20 Historic Log: Event to par. 15-22 Historic Log: Time
Par. 15-30 Alarm Log: Error Code to par. 15-32 Alarm Log: Time
NOTE
Parameters selected in par. 0-25 My Personal Menu, will
stay present, with default factory setting.
Manual initialisation
NOTE
When carrying out manual initialisation, serial communi-
cation, RFI filter settings and fault log settings are reset.
Removes parameters selected in par. 0-25 My Personal
Menu.
1. Disconnect from mains and wait until the display
turns off.
2a. Press [Status] - [Main Menu] - [OK] at the same
time while power up for Graphical LCP (GLCP)
2b. Press [Menu] while power up for LCP 101,
Numerical Display
3. Release the keys after 5 s
4. The frequency converter is now programmed
according to default settings
This parameter initialises all except:
Par. 15-00 Operating Hours
Par. 15-03 Power Up's
Par. 15-04 Over Temp's
Par. 15-05 Over Volt's
