Par. Designation [Unit
s]
0-01 Language
1-20 Motor Power [kW]
1-21 Motor Power* [HP]
1-22 Motor Voltage [V]
1-23 Motor Frequency [Hz]
1-24 Motor Current [A]
1-25 Motor Nominal Speed [RPM]
3-41 Ramp 1 Ramp-up Time [s]
3-42 Ramp 1 Ramp-down Time [s]
4-11 Motor Speed Low Limit [RPM]
4-12 Motor Speed Low Limit* [Hz]
4-13 Motor Speed High Limit [RPM]
4-14 Motor Speed High Limit* [Hz]
3-11 Jog Speed* [Hz]
5-12 Terminal 27 Digital Input
5-40 Function Relay
4.1: Quick Set-up parameters
*The display showing depends on choices
made in parameter 0-02 and 0-03. The default
setting of parameters 0-02 and 0-03 depends
on which region of the world the adjustable
frequency drive is supplied to but can be re-
programmed as required.
Parameters for Quick Set-up function:
0-01 Language
Option: Function:
Defines the language to be used in the display.
The adjustable frequency drive can be delivered with 4 different
language packages. English and German are included in all
packages. English cannot be erased or manipulated.
[0]
*
English UK Part of Language packages 1 - 4
[1] German Part of Language packages 1 - 4
[2] French Part of Language package 1
[3] Danish Part of Language package 1
[4] Spanish Part of Language package 1
[5] Italian Part of Language package 1
[6] Swedish Part of Language package 1
[7] Dutch Part of Language package 1
[10] Chinese Language package 2
[20] Finnish Part of Language package 1
[22] English US Part of Language package 4
[27] Greek Part of Language package 4
[28] Portuguese Part of Language package 4
[36] Slovenian Part of Language package 3
VLT
®
HVAC DRIVE High Power
Instruction Manual
4. How to Program
MG.11.F1.22 - VLT
®
is a registered Danfoss trademark.
77
4
