Danfoss FC 101 User Manual

I4 enclosure
130BD011.10
1 RS-485
2 Mains
3 Ground
4 Cable clamps
5 Motor
6 UDC
7 Relays
8 I/O
Illustration 3.15 I4 Enclosure
IP54, 380-480 V, 0.75-4.0 kW (1-5 HP)
130BC203.10
Illustration 3.16 IP54 I2-I3-I4 Enclosure
I6 enclosure
130BT326.10
Illustration 3.17 Connecting to Mains for I6 Enclosure
IP54, 380-480 V, 22-37 kW (30-50 HP)
130BT325.10
Illustration 3.18 Connecting to Motor for I6 Enclosure
IP54, 380-480 V, 22-37 kW (30-50 HP)
Installation Quick Guide
16 Danfoss A/S © 08/2014 All rights reserved. MG18A602
33

Danfoss FC 101 Specifications

General

Model	FC 101
Manufacturer	Danfoss
Protection Class	IP20
Relative Humidity	95% (non-condensing)
Communication Interface	RS-485
