Parameter Range Default Usage
1-48 Current at Min Inductance
for d-axis
20–200 % 100% Enter the inductance saturation point.
1-49 Current at Min Inductance
for q-axis
20–200 % 100% This parameter specifies the saturation
curve of the d- and q-inductance
values. From 20% to 100% of this
parameter, the inductances are
linearly approximated due to
parameters 1-37, 1-38, 1-44, and 1-45.
1-70 PM Start Mode
[0] Rotor Detection
[1] Parking
[0] Rotor Detection –
1-73 Flying Start
[0] Disabled
[1] Enabled
0
Select [1] Enable to enable the
frequency converter to catch a
spinning motor.
3-41 Ramp 1 Ramp Up Time
0.05–3600.0 s Size related Ramp up time from 0 to rated
1-23 Motor Frequency.
3-42 Ramp 1 Ramp Down Time
0.05–3600.0 s Size related Ramp down time from rated
1-23 Motor Frequency to 0.
4-12 Motor Speed Low Limit [Hz]
0–400 Hz 0.0 Hz Enter the minimum limit for low
speed.
4-14 Motor Speed High Limit [Hz]
0–400 Hz 100 Hz Enter the maximum limit for high
speed.
4-19 Max Output Frequency
0–400 Size related Enter the maximum output frequency
value.
30-22 Locked Rotor Detection
[0] Off
[1] On
[0] Off –
30-23 Locked Rotor Detection
Time [s]
0.05–1 s 0.10 s –
Table 4.6 Motor Set-up Wizard Settings
Changes Made
The Changes Made function lists all parameters changed
from default settings.
•
The list shows only parameters which have been
changed in the current edit-setup.
•
Parameters which have been reset to default
values are not listed.
•
The message Empty indicates that no parameters
have been changed.
Changing parameter settings
1. Press the [Menu] key to enter the Quick Menu
until indicator in display is placed above Quick
Menu.
2.
Press [
▲
] [
▼
] to select the wizard, closed loop set-
up, motor set-up or changes made, then press
[OK].
3.
Press [
▲
] [
▼
] to browse through the parameters
in the Quick Menu.
4. Press [OK] to select a parameter.
5.
Press [
▲
] [
▼
] to change the value of a parameter
setting.
6. Press [OK] to accept the change.
7.
Press either [Back] twice to enter Status, or press
[Menu] once to enter the Main Menu.
The Main Menu accesses all parameters.
1. Press the [Menu] key until indicator in display is
placed above Main Menu.
2.
Press [
▲
] [
▼
] to browse through the parameter
groups.
3. Press [OK] to select a parameter group.
4.
Press [
▲
] [
▼
] to browse through the parameters
in the specific group.
5. Press [OK] to select the parameter.
6.
Press [
▲
] [
▼
] to set/change the parameter value.
Programming Quick Guide
36 Danfoss A/S © 08/2014 All rights reserved. MG18A602
