FC 300 Profibus
Parameters
PRO 6 [106]
PRO 7 [107]
PRO 8 [108]
Function:
Instead of using par. 9-15 and 9-16 to define
profibus telegrams freely, you can use standard
telegrams defined by the profibus profile. Standard
Telegram 1 equals to PPO type 3. This parameter is
automatically set to the according value (PPO type)
when the drive is configured by a PLC.
9-23 Par ameters for Signals
Array [1000]
Option:
None [108]
3-02 Minimu m Reference [108]
3-03 Maximu
m Reference
[108]
3-12 Catch Up/Slow Down Value [108]
3-41 Ramp 1 Ramp Up Time [108]
3-42 Ra
mp 1 Ramp Down Time
[108]
3-51 Ramp 2 Ramp Up Time [108]
3-52 Ramp 2 Ramp Down Time [108]
3-8
0 Jog Ramp Time
[10
8]
3-81 Quick Stop Ramp Rime [108]
4-11 Motor Speed Low Limit [108]
4-13 Motor Speed High Limit [108]
4-16 Torque Limit Motor Mode [108]
4-17 Torque Limit Generator Mode [108]
8-90 Bus Jog 1 Speed [108]
8-91 Bus Jog 2 Speed [108]
16-00 Control Word [108]
16-01 Reference [Unit] [108]
16-02 Reference % [108]
16-03 Status Word [108]
16-05 Main Actual Value [%] [108]
16-10 Power [kW] [108]
16-11 Power [hp] [108]
16-12 Motor Voltage [108]
16-13 Frequency [108]
16-14 Motor Current [108]
16-16 Torque [108]
16-17 Speed [RPM] [108]
16-18 Motor Thermal [108]
16-19 KTY Sensor Temperature [108]
16-20 Phase Angle [108]
16-30 DC Link Voltage [108]
16-32 Brake Energy / s [108]
16-33 Brake Energy / 2 Min [108]
16-34 Heatsink Temp. [108]
16-35 Inverter Thermal [108]
16-38 SL Controller State [108]
16-39 Controlcard Temp. [108]
16-50 External Reference [ 108]
16-51 Pulse Reference [108]
16-52 Feedback [Unit] [108]
16-53 Digi Pot Reference [108]
16-60 Digital Input [108]
16-61 Terminal 53 Switch Setting [108]
16-62 Analog Input 53 [108]
16-63 Terminal 53 Switch Setting [108]
16-64 Analog Input 54 [108]
16-65 Analog Output 42 [mA] [108]
16-66 Digital Output [bin] [108]
16-67 Freq. Input #29 [Hz] [108]
16-68 Freq. Input #33 [Hz] [108]
16-69 Pulse Output #27 [Hz] [108]
16-70 Pulse Output #29 [Hz] [108]
16-80 Fieldbus CTW 1 [108]
16-82 Fieldbus REF 1 [108]
16-84 Comm Option STW [108]
16-85 FC Port CTW 1 [108]
16-90 Alarm Word [108]
16-91 Alarm Word 2 [108]
16-92 Warning Word [108]
16-93 Warning Word 2 [108]
16-94 Extended Status Word [108]
16-95 Extended Status Word 2 [108]
Function:
Contains a list of signals you can enter in par.
9-15 and 9-16. Furthermore, it automatically
sets the parameters to meet the most common
requirements.
9-27 Param eter Edit
Option:
Disabled [0]
*
Enabled [1]
Function:
It is possible to edit parameters via Profibus, the
standard Interface, or the LCP. Disable editing via
Profibus with this parameter.
9-28 Pro cess Control
Option:
Disable [0]
Enable cyclic master [ 1]
Function:
Process control (setting of Control Word, speed
reference, and process data) is possible via either
Profibus or the standard RS485 Interface but not
both at the same time. Local control is always
possible via the LCP. Control via process control is
possible with either terminals or bus depending on
the setting of par. 8-50 to 8-56.
62
MG.33.C2.02 - VLT is a registered Danfoss trademark
