FC 300 Profibus
Parameters
9-15 PC D Write Configuration
Array [10]
Option:
None [3]
3-02 Minimu m Reference [3]
3-03 Maximum Reference [3]
3-12 Catch Up/Slow Down Value [3]
3-41 Ramp 1 Ramp Up Time [3]
3-42 Ramp 1 Ramp Down Ti
me
[3]
3-51 Ramp 2 Ramp Up Time [3]
3-52 Ramp 2 Ramp Down Time [3]
3-80 Jog Ramp Time [3]
3-81 Quick Stop Ramp Time [3]
4-11 Motor Speed Low Limit [RPM]
4-13 Motor S
peed High Limit
[RPM]
4-16 Torque Limit Motor Mode [RPM]
4-17 Torque Limit Generator Mode [RPM]
8-90 B
us Jog 1 Speed
[RPM]
8-91 Bus Jog 2 Speed [RPM]
16-80 Fieldbus CTW 1 [RPM]
1
6-82 Fieldbus REF 1
[
RPM]
Function:
Assigns different parameters to PCD 3 to 10 of the
PPO’s (the number of PCD’s depends on the PPO
type). The values in PCD 3 to 10 are written to the
selected parameters as data values.
9-16 PC D Read Configuration
Array [10]
Option:
None [RPM]
16-00 Control Word [RPM]
16-01 Reference [Unit] [RPM]
16-02 Reference % [RPM]
16-03 Status Word [RPM]
16-05 Main Actual Value [%] [RPM]
16-10 Power [kW] [RPM]
16-11 Power [hp] [RPM]
16-12 Motor Voltage [RPM]
16-13 Frequency [RPM]
16-14 Motor Current [RPM]
16-16 Torque [RPM]
16-17 Speed [RPM] [RPM]
16-18 Motor Thermal [RPM]
16-19 KTY Sensor Temperature [RPM]
16-20 Phase Angle [RPM]
16-30 DC Link Voltage [RPM]
16-32 Brake Energy / s [RPM]
16-33 Brake Energy / 2 min [RPM]
16-34 Heatsink Temp. [RPM]
16-35 Inverter Thermal [RPM]
16-38 SL Controller State [RPM]
16-39 Controlcard Temp. [RPM]
16-50 External Reference [ RPM]
16-51 Pulse Reference [RPM]
16-52 Feedback [Unit] [RPM]
16-53 Digi Pot Reference [RPM]
16-60 Digital Input [RPM]
16-61 Terminal 53 Switch Setting [RPM]
16-62 Analog Input 53 [RPM]
16-63 Terminal 54 Switch Setting [RPM]
16-64 Analog Input 54 [RPM]
16-65 Analog Output 42 [mA] [RPM]
16-66 Digital Output [bin] [RPM]
16-67 Freq. Input #29 [Hz] [RPM]
16-68 Freq. Input #33 [Hz] [RPM]
16-69 Pulse Output #27 [Hz] [RPM]
16-70 Pulse Output #29 [Hz] [RPM]
16-84 Comm Option STW [Binary] [RPM]
16-85 FC port CTW 1 Signal [RPM]
16-90 Alarm Word [RPM]
16-91 Alarm Word 2 [RPM]
16-92 Warning Word [RPM]
16-93 Warning Word 2 [RPM]
16-94 Extended Status Word [RPM]
16-95 Extended Status Word 2 [RPM]
Function:
Assigns different parameters to PCD 3 to 10 of the
PPO’s (the number of PCD’s depends on the PPO
type). PCD 3 to 10 holds the actual data value of
the selected parameters.
9-18 Node Address
Range:
0 - 126
*
126.
Function:
Sets the station address. You can also set it on a
hardware switch. You can set the address in par.
9-18 only if the hardware switch is set to 126 or
127. The parameter displays the actual setting of
the switch when setting the hardware switch to
>0 and <126 . Power-up or updating par. 9-72
changes par. 9-18.
9-22 Telegram Selection
Option:
*
Standard telegram 1 [1]
PRO 1 [101]
PRO 2 [102]
PRO 3 [103]
PRO 4 [104]
PRO 5 [105]
61
MG.33.C2.02 - VLT is a registered Danfoss trademark
