FC 300 Profibus
Parameters
 PROFIBUS-specific Parameter List
Par. No.
#
Parameter description Default value Range Size index Conver-
sion index
Data
type
8-01 Control site Dig. & ctrl. word [0] [0 - 2]
8-02 Control word source FC RS485 [0] [0 - 4]
8-03 Control word timeout time 1 0.1-18000 22 -1 3
8-04 Control word timeout function Off [0] [0 - 1 0] 24 -1 3
8-05 End of timeout function Hold set-up [0] [0 - 1]
8-06 Reset control word timeout Do not reset [0] [0 - 1]
8-07 Diagnosis trigger Disable [0] [0 - 3]
8-10 Control word profile FC profile [0] [0 - x] 0
8-50 Coasting select *Logic OR [3]
8-51 Quick stop select *Logic OR [3]
8-52 DC brake select *Logic OR [3]
8-53 Start select *Logic OR [3]
8-54 Reversing select *Logic OR [3]
8-55 Set-up select *Logic OR [3]
8-56 Preset reference select *Logic OR [3]
8-90 Bus Jog 1 Speed 100 rpm
8-91 Bus Jog 2 Speed 200 rpm
9-15 PCD write configuration 006
9-16 PCD read configuration 006
9-18 Node a ddress 126 1 - 126
9-22 Telegram selection [0 - 108]
9-23 Parameter for signals 0 - 573
9-27 Parameter edit Enabled [1] [0 - 1] 0 0 6
9-28 Process control Enable cyclic master [1] [0 - 1] 0 0 6
9-53 Profibus Warning word 0 16 bits 0 0 35
9-63 Actual baud rate No baud rate found [255] 9.6-12000 kbits 0 0 5
9-64 Device identification 0 [0 - 1 0] 0 0 6
9-65 Profile number 0 8 bits 0 0 5
9-67 Control word 1 16 bits 0 0 35
9-68 Status word 1 16 bits 0 0 35
9-70 Edit Set-up Active set-up [9]
9-71 Save data values Off [0] 0 - 3 0 0 5*
9-72 Drive reset No action [0] 0 - 2 0
9-80 Defined parameters (1) 0 0-115 0 0 6
9-81 Defined parameters (2) 0-115 0 0 6
9-82 Defined parameters (3) 0 0-115 0 0 6
9-83 Defined parameters (4) 0 0-115 0 0 6
9-90 Changed parameters (1) 0-115 0 0 6
9-91 Changed parameters (2) 0 0-115 0 0 6
9-92 Changed parameters (3) 0 0-115 0 0 6
9-93 Changed parameters (4) 0 0-115 0 0 6
16-84 Comm. option STW 0 - FFFF
16-90 Alarm word 0 - FFFF
16-92 Warning word 0 - FFFF
Please refer to the FC 300 Operating I nstructions (MG.33.AX.YY) f or a compreh ensive FC 300 parameter list.
66
MG.33.C2.02 - VLT is a registered Danfoss trademark
