Danfoss FC 300 Profibus User Manual

FC 300 Profibus
Application Exa mples
 E.g.: Control Word Telegram using PPO Type 3
This example shows how the control word telegram relates to the PLC and the FC 300, using FC Control
Profile.
The control word telegram is sent from the PLC to the FC 300. PPO Type 3 is used in the example in order
to demonstrate the full range of modules. All the values shown are arbitrary, and are provided for the
purposes of demonstration only.
PCV PCD
1 2 3 4 5 6
PCA IND PVA CTW MRV PCD PCD PCD PCD
04 7C 20 00
PQW: 256 258 260 262 264 266 268 270 272 274
master → slave CTW MRV
Bit no.: 15 14 13 12 11 10 9 8 76543210
0000
010001111100
0
4 7 C
The table above indicates the bits contained within the control word, and how they are presented as process
data in PPO type 3for this example.
The following table indicates which bit functions, and which corresponding bit values are active for this
example.
Bit Bit value = 0 Bit value = 1 Bit value
00 Reference value External selection lsb 0
01 Reference value External selection msb 0
02 DC brake Ramp 1
03 Coasting Enable 1
C
04 Quick stop Ramp 1
05 Freeze output Ramp enable 1
06 Ramp stop Start 1
07 No function Reset 0
7
08 No function Jog 0
09 Ramp 1 Ramp 2 0
10 Data not valid V alid 1
11 No function Relay 01 active 0
4
12 No function Relay 02 active 0
13 Parameter set-up Selection lsb 0
14 Parameter set-up Selection msb 0
15 No function Reversing 0
0
Function active
Function inactive
71
MG.33.C2.02 - VLT is a registered Danfoss trademark
