Danfoss FC 300 Profibus User Manual

FC 300 Profibus
Troubleshooting
FC 300
Bit (Hex) Unit di-
agnose
bit
PROFIBUS warning word (Par.
9-53)
00000001 160 Connection with DP-m aster is not
ok
00000002 161 Timeout action active
00000004 162 FDL (Field-bus Data link Layer) is
not ok
00000008 163 Clear data command received
00000010 164 Actual value is not updated
00000020 165 Baudrate search
00000040 166 PROFIBUS ASIC is not transmitting
00000080 167 Initialising of PROFIBUS is not ok
00000100 152 Drive is tripped
00000200 153 Internal CAN error
00000400 154 Wrong configuration data from
PLC
00000800 155 Wrong ID sent by PLC
00001000 156 Internal error occurred
00002000 157 Not configured
00004000 158 Clear command received
00008000 159 Warning 34 active
FC 300
Bit (Hex) Comm. option STW (Par. 16-84)
00000001 parameterization ok
00000002 con figuration ok
00000004 clearmode active
00000008 baudrate search
00000010 waiting for parameterization
00000020 waiting for configuration
00000040 in data exchange
00000080 not u sed
00000100 not u sed
00000200 not u sed
00000400 not u sed
00000800 MCL2/1 connected
00001000 MCL2/2 connected
00002000 MCL2/3 connected
00004000 data transport active
00008000 not u sed
NB!:
Par. 16-84 Comm. Option STW is not part
of extended diagnosis.
 Warning and Alarm Messages
There is a clear distinction between alarms a nd warnings. When there is an alarm, the frequency converter
will enter a fault condition. After the cause for the alarm has been cleared, the master will have to
acknowledge the alarm message before the frequency converter can start operating again. A warning, on
the other hand, may come when a warning condition appears, then disappear when conditions return to
normal, without interfering with the process.
Warnings
Warnings within the frequency converter are represented by a single bit within a warning word. A warning
word is always an active parameter. Bit status FALSE [0] means no warning, while bit status TRUE [1] means
warning. Any bit change in the warning word will be notified by a change of bit 7 in the status word.
Alarms
Following an alarm message the frequency converter will enter Fau lt condition. Only after the fault has been
alleviated and the master has a cknowledged the a larm message by setting bit 7 in the control word, can the
frequency converter resume operation. Alarms within the frequency converter are represented by a single bit
within an alarm word. An alarm word is always an action parameter. Bit status FALSE [0] means no fault,
while bit status TRUE [1] means fault.
 Fault Messages via DP Diagnosis
The standard DP function features an on-line diagnosis, which is active during DP initialisation as well as
data exchange mode.
82
MG.33.C2.02 - VLT is a registered Danfoss trademark
