FC 300 Profibus
Parameters
- Disable: Disables process control via Profibus, and
enables process c on trol v ia standard RS485.
- Enable cyclic master: Enables process control
via Profibus Master Class 1, and disables process
control via standard RS485 bus or Master class 2.
9-53 Pr ofibus Warning Word
Option:
Bit: Meaning:
0 Connection with DP-master is not
1 Timeout action active
2 FDL (Field-bus Data link Layer) is not ok
3 Clear data command received
4 Actual value is not updated
5 Baudrate search
6 PROFIBUS ASIC is not transmitting
7 Initializing of PROFIBUS is not ok
8 Drive is tripped
9 Internal CAN error
10 Wrong ID sent by PLC
11 Internal error occured
12 Not configured
13 Clear command received
14 Warning 34 active
Function:
Displays Profibus communication warnings.
9-63 A ctual Baud Rate
Option:
Read only [1]
9.6 kbit/s [0]
19.2 kbit/s [1]
93.75 kbit/s [2]
187.5 kbit/s [3]
500 kbit/s [4]
1500 kbit/s [6]
3000 kbit/s [7]
6000 kbit/s [8]
12000 kbit/s [9]
31.25 kbit/s [10]
45.45 kbit/s [11]
No baudrate found [255]
Function:
Displays the actual PROFIBUS baud rate. The
Profibus Master automatically sets the baud rate.
9-64 D evice Identification
Array [10]
Option:
Read only [255]
Array [10]
Index Content Value
[0] Manufacturer 128 (for Danfoss)
[1] Device type 1
[2] Version xxyy
[3] Firmware date year yyyy
[4] Firmware date month ddmm
[5] No. of axes variable
[6] Vendor specific: PB
Version
xxyy
[7] Vendor specific:
Database Version
xxyy
[8] Vendor specific: AOC
Version
xxyy
[9] Vendor specific: MOC
Version
xxyy
Function:
The device identification parameter. The data type
is "Array[n] of Unsigned16“. The assignment of the
first subindexes is defined and shown in the table
above.
9-65 Pro file Number
Option:
Read only
0. - 0.
*
0.
Function:
Contains the profile identification. Byte 1 contains
the profile number and byte 2 the version number
of the profile.
9-67 Co ntrol Word 1
Range:
Read only
No LCP access
0. - 65535.
*
0.
Function:
Accepts the Control word from a Master Class 2 in
the same format as PCD 1. If control priority is set
to Master Class 2, the Control word for the drive
is taken from this parameter, whereas cyclical and
acyclic reference from a Master Class 2 is ignored.
This parameter is only visible for Profibus Master
Class 2, not for Master Class 1, standard bu s or LCP.
9-68 Sta tus Word 1
Range:
Read only
No LCP access
0. - 65535.
*
0.
63
MG.33.C2.02 - VLT is a registered Danfoss trademark
