8-13 Configurable Status Word STW
Option: Function:
[81] SL Digital
Output B
SL Controller Action. The input will go high
whenever the Smart Logic Action [39] Set
dig. out. A high is executed. The input will
go low whenever the Smart Logic Action
[33] Set dig. out. A low is executed.
[82] SL Digital
Output C
SL Controller Action. The input will go high
whenever the Smart Logic Action [40] Set
dig. out. A high is executed. The input will
go low whenever the Smart Logic Action
[34] Set dig. out. A low is executed.
[83] SL Digital
Output D
SL Controller Action. The input will go high
whenever the Smart Logic Action [41] Set
dig. out. A high is executed. The input will
go low whenever the Smart Logic Action
[35] Set dig. out. A low is executed.
[84] SL Digital
Output E
SL Controller Action. The input will go high
whenever the Smart Logic Action [42] Set
dig. out. A high is executed. The input will
go low whenever the Smart Logic Action
[36] Set dig. out. A low is executed.
[85] SL Digital
Output F
SL Controller Action. The input will go high
whenever the Smart Logic Action [43] Set
dig. out. A high is executed. The input will
go low whenever the Smart Logic Action
[37] Set dig. out. A low is executed
8-14 Configurable Control Word CTW
Option: Function:
Selection of control word bit 10 if it is
active low or active high
[0] None
[1]
*
Profile default
[2] CTW val., act. low
3.10.3 8-3* FC Port Settings
8-30 Protocol
Option: Function:
[0]
*
FC
[1] FC MC Select the protocol for the FC (standard) port.
[2] Modbus RTU
8-31 Address
Range: Function:
Application
dependent
*
[Application
dependant]
Enter the address for the FC
(standard) port.
Valid range: 1–126.
8-32 FC Port Baud Rate
Option: Function:
[0] 2400 Baud Baud rate selection for the FC (standard) port.
[1] 4800 Baud
[2]
*
9600 Baud
[3] 19200 Baud
[4] 38400 Baud
[5] 57600 Baud
[6] 76800 Baud
[7] 115200 Baud
8-33 Parity / Stop Bits
Option: Function:
[0]
*
Ev. Par. 1 Stop Bit
[1] Odd Par. 1 Stop Bit
[2] No Parity, 1 Stop Bit
[3] No Par. 2 Stop Bits
8-34 Estimated cycle time
Range: Function:
0 ms
*
[0 - 1000000
ms]
In a noisy environments, the interface may
be blocked by due to overload of bad
frames. This parameter specifies the time
between two consecutive frames on the
network. If the interface does not detect
valid frames in that time it flushes the
receive buffer.
8-35 Minimum Response Delay
Range: Function:
10 ms
*
[Application
dependant]
Specify the minimum delay time
between receiving a request and
transmitting a response. This is used
for overcoming modem turnaround
delays.
8-36 Max Response Delay
Range: Function:
Application
dependent
*
[Application
dependant]
Specify the maximum
permissible delay time
between transmitting a
request and receiving a
response. Exceeding this delay
time will cause control word
timeout.
Parameter Descriptions FC 300 Programming Guide
3-84 MG.33.MA.22 - VLT
®
is a registered Danfoss trademark
3
