13-01 Start Event
Option: Function:
[47] Up key Up key [47] The up key is pressed.
[48] Down key Down key [48] The down key is pressed.
[50] Comparator 4 Comparator 4 [50] Use the result of
comparator 4.
[51] Comparator 5 Comparator 5 [51] Use the result of
comparator 5.
[60] Logic rule 4 Logic rule 4 [60] Use the result of logic rule
4.
[61] Logic rule 5 Logic rule 5 [61] Use the result of logic rule
5.
13-02 Stop Event
Select the Boolean (TRUE or FALSE) input to activate Smart Logic
Control.
Option: Function:
[0] * FALSE For descriptions [0] - [61], see
13-01 Start Event Start Event
[1] TRUE
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reverse
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Timeout 0
13-02 Stop Event
Select the Boolean (TRUE or FALSE) input to activate Smart Logic
Control.
Option: Function:
[31] SL Timeout 1
[32] SL Timeout 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto-reset Trip
[43] OK key
[44] Reset key
[45] Left key
[46] Right key
[47] Up key
[48] Down key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Timeout 3 SL Timeout 3 [70] Smart Logic
Controller timer 3 is timed out.
[71] SL Timeout 4 SL Timeout 4 [71] Smart Logic
Controller timer 4 is timed out.
[72] SL Timeout 5 SL Timeout 5 [72] Smart Logic
Controller timer 5 is timed out.
[73] SL Timeout 6 SL- Timeout 6 [73] Smart Logic
Controller timer 6 is timed out.
[74] SL Timeout 7 SL Timeout 7 [74] Smart Logic
Controller timer 7 is timed out.
[75] Start command given
[76] Digital input x30 2
[77] Digital input x30 3
[78] Digital input x30 4
[79] Digital input x46/1
[80] Digital input x46/3
[81] Digital input x46/5
[82] Digital input x46/7
[83] Digital input x46/9
[84] Digital input x46/11
[85] Digital input x46/13
Parameter Descriptions FC 300 Programming Guide
