13-10 Comparator Operand
Array [6]
Option: Function:
[55] Reversing Reverse [55] The output is high when the
adjustable frequency drive is running
counter-clockwise (the logical product of
the status bits “running” AND “reverse”)
[56] In range In range [56] The motor is running within
the programmed current and speed
ranges set in 4-50 Warning Current Low to
4-53 Warning Speed High.
[60] On reference On reference [60] The motor is running on
reference.
[61] Below Reference
Low
Below reference, low [61] The motor is
running below the value given in
4-54 Warning Reference Low
[62] Above ref, high Above reference, high [62] The motor is
running above the value given in
4-55 Warning Reference High
[65] Torque limit Torque limit [65] The torque limit, set in
4-16 Torque Limit Motor Mode or
4-17 Torque Limit Generator Mode, has
been exceeded.
[66] Current limit Current limit [66] The motor current limit,
set in 4-18 Current Limit, has been
exceeded.
[67] Out of current
range
Out of current range [67] The motor
current is outside the range set in
4-18 Current Limit.
[68] Below I low Below I low [68] The motor current is
lower than set in 4-50 Warning Current
Low.
[69] Above I high Above I high [69] The motor current is
higher than set in 4-51 Warning Current
High.
[70] Out of speed
range
Out of speed range [70] The speed is
outside the range set in 4-52 Warning
Speed Low and 4-53 Warning Speed High.
[71] Below speed low Below speed low [71] The output speed is
lower than the setting in 4-52 Warning
Speed Low.
[72] Above speed
high
Above speed high [72] The output speed is
higher than the setting in 4-53 Warning
Speed High.
[75] Out of feedb.
range
Out of feedb. Range [75] The feedback is
outside the range set in 4-56 Warning
Feedback Low and 4-57 Warning Feedback
High.
13-10 Comparator Operand
Array [6]
Option: Function:
[76] Below feedb. low Below feedb. Low [76] The feedback is
below the limit set in par. 4-56 Warning
Feedback Low.
[77] Above feedb.
high
Above feedb. High [77] The feedback is
above the limit set in 4-57 Warning
Feedback High.
[80] Thermal warning Thermal warning [80] The thermal
warning turns on when the temperature
exceeds the limit in the motor, the
adjustable frequency drive, the brake
resistor or thermistor.
[82] Line pwr out of
range
Mains out of range [82] The AC line
voltage is outside the specified voltage
range.
[85] Warning Warning [85] A warning is active.
[86] ALARM (Trip) Alarm (trip) [86] A (trip) alarm is active.
[87] ALARM (Trip
Lock)
Alarm (trip lock) [87] A (Trip lock) alarm is
active.
[90] Bus OK Bus OK [90] Active communication (no
timeout) via the serial communication
port.
[91] Torque limit &
stop
Torque limit & stop [91] If the adjustable
frequency drive has received a stop signal
and is at the torque limit, the signal is
logic “0.”
[92] Brake fault (IGBT) Brake fault (IGBT) [92] The brake IGBT is
short circuited.
[93] Mech. brake
control
Mech. brake control [93] The mechanical
brake is active.
[94] Safe stop active
[100] Comparator 0 Comparator 0 [100] The result of
comparator 0.
[101] Comparator 1 Comparator 1 [101] The result of
comparator 1.
[102] Comparator 2 Comparator 2 [102] The result of
comparator 2.
[103] Comparator 3 Comparator 3 [103] The result of
comparator 3.
[104] Comparator 4 Comparator 4 [104] The result of
comparator 4.
[105] Comparator 5 Comparator 5 [105] The result of
comparator 5.
[110] Logic rule 0 Logic rule 0 [110] The result of logic rule
0.
Parameter Descriptions FC 300 Programming Guide
3-110 MG.33.MA.22 - VLT
®
is a registered Danfoss trademark
3
