3.16.4 15-3* Alarm Log
Parameters in this group are array parameters, where up to
10 fault logs can be viewed. [0] is the most recent logged
data, and [9] the oldest. Error codes, values and time stamp
can be viewed for all logged data.
15-30 Fault Log: Error Code
Array [10]
Range: Function:
0
*
[0 - 255 ] View the error code and look up its meaning in the
Troubleshooting chapter of the FC 300 Design
Guide.
15-31 Alarm Log: Value
Array [10]
Range: Function:
0 N/A
*
[-32767 - 32767
N/A]
View an extra description of the error.
This parameter is mostly used in
combination with alarm 38 ‘internal
fault’.
15-32 Alarm Log: Time
Array [10]
Range: Function:
0 s
*
[0 - 2147483647 s] View the time when the logged event
occurred. Time is measured in seconds
from adjustable frequency drive start-
up.
3.16.5 15-4* Drive Identification
Parameters containing read only information about the
hardware and software configuration of the adjustable
frequency drive.
15-40 FC Type
Range: Function:
0
*
[0 - 0 ] View the adjustable frequency drive type. The
readout is identical to the FC 300 Series power field
of the type code definition, characters 1-6.
15-41 Power Section
Range: Function:
0
*
[0 - 0 ] View the FC type. The readout is identical to the FC
300 Series power field of the type code definition,
characters 7-10.
15-42 Voltage
Range: Function:
0
*
[0 - 0 ] View the FC type. The readout is identical to the FC
300 Series power field of the type code definition,
characters 11-12.
15-43 Software Version
Range: Function:
0 N/A
*
[0 - 0 N/A] View the combined SW version (or ‘package
version’) consisting of power SW and control
SW.
15-44 Ordered Typecode String
Range: Function:
0 N/A
*
[0 - 0 N/A] View the type code string used for re-
ordering the adjustable frequency drive in its
original configuration.
15-45 Actual Typecode String
Range: Function:
0 N/A
*
[0 - 0 N/A] View the actual type code string.
15-46 Adj Freq Dr Ordering No.
Range: Function:
0 N/A
*
[0 - 0 N/A] View the 8-digit ordering number used for
re-ordering the adjustable frequency drive in
its original configuration.
15-47 Power Card Ordering No.
Range: Function:
0 N/A
*
[0 - 0 N/A] View the power card ordering number.
15-48 LCP ID Num.
Range: Function:
0 N/A
*
[0 - 0 N/A] View the LCP ID number.
15-49 SW ID Control Card
Range: Function:
0 N/A
*
[0 - 0 N/A] View the control card software version
number.
15-50 SW ID Power Card
Range: Function:
0 N/A
*
[0 - 0 N/A] View the power card software version
number.
15-51 Adj Freq Dr Serial No.
Range: Function:
0 N/A
*
[0 - 0 N/A] View the adjustable frequency drive serial
number.
Parameter Descriptions FC 300 Programming Guide
3-130 MG.33.MA.22 - VLT
®
is a registered Danfoss trademark
3
