Par. 1-10 - Motor Construction AC motor PM Non-salient Motor
Par. 1-01 - Motor Control Principle
U/f mode VVC+
Flux open-
loop
Flux closed-
loop
U/f mode
Flux open-
loop
Flux closed-
loop
Par. 1-80 - Stop Function
+ + + + + + +
Par. 1-81 - Min Speed Funct. at
Stop [RPM] (Par. 002 = RPM)
+ + + + + + +
Par. 1-82 - Min Speed Funct. at
Stop [Hz] (Par. 002 = Hz)
+ + + + + + +
Par. 1-83 - Precise Stop Function
+ + + + + + +
Par. 1-84 - Precise Stop Counter
Value
+ + + + + + +
Par. 1-85 - Precise Stop Speed
Comp Delay
+ + + + + + +
Par. 1-90 - Motor Thermal
Protection
+ + + +
Par. 1-91 - Motor External Fan + + + +
Par. 1-93 - Thermistor Resource + + + +
Par. 1-95 - KTY Sensor Type + + + +
Par. 1-96 - KTY Thermistor
Resource
+ + + +
Par. 1-97 - KTY Threshold Level + + + +
Par. 2-00 - DC Hold Current + + + +
Par. 2-01 - DC Brake Current + + + +
Par. 2-02 - DC Braking Time + + + +
Par. 2-03 - DC Brake Cut-in Speed
[RPM]
+ + + +
Par. 2-04 - DC Brake Cut-in Speed
[Hz]
+ + + +
Par. 2-05 - Maximum Reference + + + +
Par. 2-10 - Brake Function +
see 9)
+ + +
Par. 2-11 - Brake Resistor + + + +
Par. 2-12 - Brake Power Limit + + + +
Par. 2-13 - Brake Power Monitoring + + + +
Par. 2-15 - Brake Check +
see 9)
+ + +
Par. 2-16 - AC Brake Max Current - + + +
Par. 2-17 - Over-voltage Control + + + +
Par. 2-18 - Brake Check Condition + + + +
Par. 2-19 - Over-voltage Gain + + + -
Par. 2-20 - Release Brake Current + + + +
Par. 2-21 - Activate Brake Speed
[RPM]
+ + + +
Par. 2-22 - Activate Brake Speed
[Hz]
+ + + +
Par. 2-23 - Activate Brake Delay + + + +
Par. 2-24 - Stop Delay - - - +
Par. 2-25 - Brake Release Time - - - +
Par. 2-26 - Torque Ref - - - +
Par. 2-27 - Torque Ramp Time - - - +
Par. 2-28 - Gain Boost Factor - - - +
9) Not AC brake
Parameter Lists FC 300 Programming Guide
4-4 MG.33.MA.22 - VLT
®
is a registered Danfoss trademark
4
4
