Danfoss FC 300 Series User Manual

4.1.23 34-** MCO Data Readouts
Par.
No. #
Parameter description Default value 4 set-up FC 302
only
Change
during
operation
Conver-
sion index
Type
34-0* PCD Write Par.
34-01 PCD 1 Write to MCO 0 N/A All set-ups TRUE 0 Uint16
34-02 PCD 2 Write to MCO 0 N/A All set-ups TRUE 0 Uint16
34-03 PCD 3 Write to MCO 0 N/A All set-ups TRUE 0 Uint16
34-04 PCD 4 Write to MCO 0 N/A All set-ups TRUE 0 Uint16
34-05 PCD 5 Write to MCO 0 N/A All set-ups TRUE 0 Uint16
34-06 PCD 6 Write to MCO 0 N/A All set-ups TRUE 0 Uint16
34-07 PCD 7 Write to MCO 0 N/A All set-ups TRUE 0 Uint16
34-08 PCD 8 Write to MCO 0 N/A All set-ups TRUE 0 Uint16
34-09 PCD 9 Write to MCO 0 N/A All set-ups TRUE 0 Uint16
34-10 PCD 10 Write to MCO 0 N/A All set-ups TRUE 0 Uint16
34-2* PCD Read Par.
34-21 PCD 1 Read from MCO 0 N/A All set-ups TRUE 0 Uint16
34-22 PCD 2 Read from MCO 0 N/A All set-ups TRUE 0 Uint16
34-23 PCD 3 Read from MCO 0 N/A All set-ups TRUE 0 Uint16
34-24 PCD 4 Read from MCO 0 N/A All set-ups TRUE 0 Uint16
34-25 PCD 5 Read from MCO 0 N/A All set-ups TRUE 0 Uint16
34-26 PCD 6 Read from MCO 0 N/A All set-ups TRUE 0 Uint16
34-27 PCD 7 Read from MCO 0 N/A All set-ups TRUE 0 Uint16
34-28 PCD 8 Read from MCO 0 N/A All set-ups TRUE 0 Uint16
34-29 PCD 9 Read from MCO 0 N/A All set-ups TRUE 0 Uint16
34-30 PCD 10 Read from MCO 0 N/A All set-ups TRUE 0 Uint16
34-4* Inputs & Outputs
34-40 Digital Inputs 0 N/A All set-ups TRUE 0 Uint16
34-41 Digital Outputs 0 N/A All set-ups TRUE 0 Uint16
34-5* Process Data
34-50 Actual Position 0 N/A All set-ups TRUE 0 Int32
34-51 Commanded Position 0 N/A All set-ups TRUE 0 Int32
34-52 Actual Master Position 0 N/A All set-ups TRUE 0 Int32
34-53 Slave Index Position 0 N/A All set-ups TRUE 0 Int32
34-54 Master Index Position 0 N/A All set-ups TRUE 0 Int32
34-55 Curve Position 0 N/A All set-ups TRUE 0 Int32
34-56 Track Error 0 N/A All set-ups TRUE 0 Int32
34-57 Synchronizing Error 0 N/A All set-ups TRUE 0 Int32
34-58 Actual Velocity 0 N/A All set-ups TRUE 0 Int32
34-59 Actual Master Velocity 0 N/A All set-ups TRUE 0 Int32
34-60 Synchronizing Status 0 N/A All set-ups TRUE 0 Int32
34-61 Axis Status 0 N/A All set-ups TRUE 0 Int32
34-62 Program Status 0 N/A All set-ups TRUE 0 Int32
34-64 MCO 302 Status 0 N/A All set-ups TRUE 0 Uint16
34-65 MCO 302 Control 0 N/A All set-ups TRUE 0 Uint16
34-7* Diagnosis readouts
34-70 MCO Alarm Word 1 0 N/A All set-ups FALSE 0 Uint32
34-71 MCO Alarm Word 2 0 N/A All set-ups FALSE 0 Uint32
Parameter Lists FC 300 Programming Guide
MG.33.MA.22 - VLT
®
is a registered Danfoss trademark 4-35
4
4
