Danfoss FC 300 Series User Manual

4.1.24 35-** Sensor Input Option
Par.
No. #
Parameter description Default value 4 set-up FC 302
only
Change
during
operation
Conver-
sion index
Type
35-0* Temp. Input Mode
35-00 Term. X48/4 Temp. Unit [60] °C All set-ups TRUE - Uint8
35-01 Term. X48/4 Input Type [0] Not Connected All set-ups TRUE - Uint8
35-02 Term. X48/7 Temp. Unit [60] °C All set-ups TRUE - Uint8
35-03 Term. X48/7 Input Type [0] Not Connected All set-ups TRUE - Uint8
35-04 Term. X48/10 Temp. Unit [60] °C All set-ups TRUE - Uint8
35-05 Term. X48/10 Input Type [0] Not Connected All set-ups TRUE - Uint8
35-06 Temperature Sensor Alarm Function [5] Stop and trip All set-ups TRUE - Uint8
35-1* Temp. Input X48/4
35-14 Term. X48/4 Filter Time Constant 0.001 s All set-ups TRUE -3 Uint16
35-15 Term. X48/4 Temp. Monitor [0] Disabled All set-ups TRUE - Uint8
35-16 Term. X48/4 Low Temp. Limit ExpressionLimit All set-ups TRUE 0 Int16
35-17 Term. X48/4 High Temp. Limit ExpressionLimit All set-ups TRUE 0 Int16
35-2* Temp. Input X48/7
35-24 Term. X48/7 Filter Time Constant 0.001 s All set-ups TRUE -3 Uint16
35-25 Term. X48/7 Temp. Monitor [0] Disabled All set-ups TRUE - Uint8
35-26 Term. X48/7 Low Temp. Limit ExpressionLimit All set-ups TRUE 0 Int16
35-27 Term. X48/7 High Temp. Limit ExpressionLimit All set-ups TRUE 0 Int16
35-3* Temp. Input X48/10
35-34 Term. X48/10 Filter Time Constant 0.001 s All set-ups TRUE -3 Uint16
35-35 Term. X48/10 Temp. Monitor [0] Disabled All set-ups TRUE - Uint8
35-36 Term. X48/10 Low Temp. Limit ExpressionLimit All set-ups TRUE 0 Int16
35-37 Term. X48/10 High Temp. Limit ExpressionLimit All set-ups TRUE 0 Int16
35-4* Analog Input X48/2
35-42 Term. X48/2 Low Current 4.00 mA All set-ups TRUE -5 Int16
35-43 Term. X48/2 High Current 20.00 mA All set-ups TRUE -5 Int16
35-44 Term. X48/2 Low Ref./Feedb. Value 0.000 N/A All set-ups TRUE -3 Int32
35-45 Term. X48/2 High Ref./Feedb. Value 100.000 N/A All set-ups TRUE -3 Int32
35-46 Term. X48/2 Filter Time Constant 0.001 s All set-ups TRUE -3 Uint16
Parameter Lists FC 300 Programming Guide
4-36 MG.33.MA.22 - VLT
®
