5-20 Terminal X46/1 Digital Input
Option: Function:
[0]
*
No operation This parameter is active when option module
MCB 113 is installed in the adjustable
frequency drive. Functions are described
under 5-1* Digital Inputs
5-21 Terminal X46/3 Digital Input
Option: Function:
[0]
*
No operation This parameter is active when option
moduleMCB 113 is installed in the adjustable
frequency drive. Functions are described
under 5-1* Digital Inputs
5-22 Terminal X46/5 Digital Input
Option: Function:
[0]
*
No operation This parameter is active when option
moduleMCB 113 is installed in the adjustable
frequency drive. Functions are described
under 5-1* Digital Inputs
5-23 Terminal X46/7 Digital Input
Option: Function:
[0]
*
No operation This parameter is active when option
moduleMCB 113 is installed in the adjustable
frequency drive. Functions are described
under 5-1* Digital Inputs
5-24 Terminal X46/9 Digital Input
Option: Function:
[0]
*
No operation This parameter is active when option module
MCB 113 is installed in the adjustable
frequency drive. Functions are described
under 5-1* Digital Inputs
5-25 Terminal X46/11 Digital Input
Option: Function:
[0]
*
No operation This parameter is active when option
moduleMCB 113 is installed in the adjustable
frequency drive. Functions are described
under 5-1* Digital Inputs
5-26 Terminal X46/13 Digital Input
Option: Function:
[0]
*
No operation This parameter is active when option module
MCB 113 is installed in the adjustable
frequency drive. Functions are described
under 5-1* Digital Inputs
3.7.3 5-3* Digital Outputs
The 2 solid-state digital outputs are common for terminals 27
and 29. Set the I/O function for terminal 27 in 5-01 Terminal
27 Mode, and set the I/O function for terminal 29 in
5-02 Terminal 29 Mode. These parameters cannot be adjusted
while the motor is running.
[0] No operation Default for all digital outputs and relay
outputs
[1] Control ready The control card is ready. For example,
Feedback from a drive where the control
is supplied by an external 24 V (MCB 107)
and the main power to drive is not
detected.
[2] Drive ready The adjustable frequency drive is ready
for operation and applies a supply signal
on the control board.
[3] Drive ready /
remote control
The adjustable frequency drive is ready
for operation and is in Auto On mode.
[4] Enable / no
warning
Ready for operation. No start or stop
command is been given (start/disable).
No warnings are active.
[5] VLT running Motor is running and shaft torque is
present.
[6] Running / no
warning
Output speed is higher than the speed
set in 1-81 Min Speed for Function at Stop
[RPM]. The motor is running and there are
no warnings.
[7] Run in range/no
warning
Motor is running within the programmed
current and speed ranges set in
4-50 Warning Current Low to 4-53 Warning
Speed High. There are no warnings.
[8] Run on
reference / no
warning
Motor runs at reference speed. No
warnings.
[9] Alarm An alarm activates the output. There are
no warnings.
[10] Alarm or warning An alarm or a warning activates the
output.
[11] At torque limit The torque limit set in 4-16 Torque Limit
Motor Mode or 4-17 Torque Limit
Generator Mode has been exceeded.
[12] Out of current
range
The motor current is outside the range
set in 4-18 Current Limit.
[13] Below current,
low
Motor current is lower than set in
4-50 Warning Current Low.
[14] Above current,
high
Motor current is higher than set in
4-51 Warning Current High.
[15] Out of speed
range
Output frequency is outside the
frequency ranges set in 4-52 Warning
Speed Low and 4-53 Warning Speed High.
[16] Below speed, low Output speed is lower than the setting in
4-52 Warning Speed Low.
