[17] Above speed,
high
Output speed is higher than the setting
in 4-53 Warning Speed High.
[18] Out of feedback
range
Feedback is outside the range set in
4-56 Warning Feedback Low and
4-57 Warning Feedback High.
[19] Below feedback
low
Feedback is below the limit set in
4-56 Warning Feedback Low.
[20] Above feedback
high
Feedback is above the limit set in
4-57 Warning Feedback High.
[21] Thermal warning The thermal warning turns on when the
temperature exceeds the limit in the
motor, the adjustable frequency drive,
the brake resistor, or the thermistor.
[22] Ready, no
thermal warning
The adjustable frequency drive is ready
for operation and there is no overtem-
perature warning.
[23] Remote, ready,
no thermal
warning
The adjustable frequency drive is ready
for operation and is in auto on mode.
There is no overtemperature warning.
[24] Ready, no over/
undervoltage
The adjustable frequency drive is ready
for operation and the AC line voltage is
within the specified voltage range (see
General Specifications section in the
Design Guide).
[25] Reverse Reversing. Logic ‘1’ when CW rotation of
the motor. Logic ‘0’ when CCW rotation
of the motor. If the motor is not rotating,
the output will follow the reference.
[26] Bus OK Active communication (no timeout) via
the serial communication port.
[27] Torque limit and
stop
Use in performing a coasting stop and in
torque limit condition. If the adjustable
frequency drive has received a stop
signal and is at the torque limit, the
signal is Logic ‘0’.
[28] Brake, no brake
warning
Brake is active and there are no warnings.
[29] Brake ready, no
fault
Brake is ready for operation and there are
no faults.
[30] Brake fault (IGBT) Output is Logic ‘1’ when the brake IGBT is
short-circuited. Use this function to
protect the adjustable frequency drive if
there is a fault on the brake modules. Use
the output/relay to cut out the main
voltage from the adjustable frequency
drive.
[31] Relay 123 Relay is activated when Control Word [0]
is selected in par. group 8-**.
[32] Mechanical brake
control
Enables control of an external mechanical
brake; see description in the section
Control of Mechanical Brake, and par.
group 2-2*.
[33] Safe stop
activated (FC 302
only)
Indicates that the safe stop on terminal
37 has been activated.
[40] Out of ref range Active when the actual speed is outside
settings in 4-52 Warning Speed Low to
4-55 Warning Reference High.
[41] Below reference
low
Active when actual speed is below speed
reference setting.
[42] Above reference
high
Active when actual speed is above speed
reference setting
[43] Extended PID
Limit
[45] Bus Ctrl Controls output via bus. The state of the
output is set in 5-90 Digital & Relay Bus
Control. The output state is retained in
the event of bus timeout.
[46] Bus Ctrl On at
timeout
Controls output via bus. The state of the
output is set in 5-90 Digital & Relay Bus
Control. In the event of a bus timeout, the
output state is set high (On).
[47] Bus Ctrl Off at
timeout
Controls output via bus. The state of the
output is set in 5-90 Digital & Relay Bus
Control. In the event of a bus timeout, the
output state is set low (Off).
[51] MCO controlled Active when a MCO 302 or MCO 305 is
connected. The output is controlled from
option.
[55] Pulse output
[60] Comparator 0 See par. group 13-1*. If Comparator 0 is
evaluated as TRUE, the output will go
high. Otherwise, it will be low.
[61] Comparator 1 See par. group 13-1*. If Comparator 1 is
evaluated as TRUE, the output will go
high. Otherwise, it will be low.
[62] Comparator 2 See par. group 13-1*. If Comparator 2 is
evaluated as TRUE, the output will go
high. Otherwise, it will be low.
[63] Comparator 3 See par. group 13-1*. If Comparator 3 is
evaluated as TRUE, the output will go
high. Otherwise, it will be low.
[64] Comparator 4 See par. group 13-1*. If Comparator 4 is
evaluated as TRUE, the output will go
high. Otherwise, it will be low.
[65] Comparator 5 See par. group 13-1*. If Comparator 5 is
evaluated as TRUE, the output will go
high. Otherwise, it will be low.
[70] Logic Rule 0 See par. group 13-4*. If Logic Rule 0 is
evaluated as TRUE, the output will go
high. Otherwise, it will be low.
[71] Logic Rule 1 See par. group 13-4*. If Logic Rule 1 is
evaluated as TRUE, the output will go
high. Otherwise, it will be low.
Parameter Descriptions FC 300 Programming Guide
3-54 MG.33.MA.22 - VLT
®
is a registered Danfoss trademark
3
