5-71 Term 32/33 Encoder Direction
Option: Function:
Change the detected encoder rotation
direction without changing the wiring to the
encoder.
[0]
*
Clockwise Sets channel A 90° (electrical degrees) behind
channel B upon clockwise rotation of the
encoder shaft.
[1] Counter-
clockwise
Sets channel A 90° (electrical degrees) ahead
of channel B upon clockwise rotation of the
encoder shaft.
This parameter cannot be adjusted while the motor is
running.
3.7.8 5-9* Bus Controlled
This parameter group selects digital and relay outputs via a
serial communication bus setting.
5-90 Digital & Relay Bus Control
Range: Function:
0
*
[0 - 2147483647 ] This parameter holds the state of the
digital outputs and relays that is controlled
by bus.
A logical '1' indicates that the output is
high or active.
A logical '0' indicates that the output is
low or inactive.
Bit 0 Digital Output Terminal 27
Bit 1 Digital Output Terminal 29
Bit 2 Digital Output Terminal X 30/6
Bit 3 Digital Output Terminal X 30/7
Bit 4 Relay 1 output terminal
Bit 5 Relay 2 output terminal
Bit 6 Option B Relay 1 output terminal
Bit 7 Option B Relay 2 output terminal
Bit 8 Option B Relay 3 output terminal
Bit 9-15 Reserved for future terminals
Bit 16 Option C Relay 1 output terminal
Bit 17 Option C Relay 2 output terminal
Bit 18 Option C Relay 3 output terminal
Bit 19 Option C Relay 4 output terminal
Bit 20 Option C Relay 5 output terminal
Bit 21 Option C Relay 6 output terminal
Bit 22 Option C Relay 7 output terminal
Bit 23 Option C Relay 8 output terminal
Bit 24-31 Reserved for future terminals
5-93 Pulse Out #27 Bus Control
Range: Function:
0.00 %
*
[0.00 - 100.00
%]
Set the output frequency transferred to
the output terminal 27 when the
terminal is configured as 'Bus
Controlled' in 5-60 Terminal 27 Pulse
Output Variable [45].
5-94 Pulse Out #27 Timeout Preset
Range: Function:
0.00 %
*
[0.00 - 100.00
%]
Set the output frequency transferred to
the output terminal 27 when the terminal
is configured as 'Bus Ctrl Timeout' in
5-60 Terminal 27 Pulse Output Variable
[48]. And a timeout is detected.
5-95 Pulse Out #29 Bus Control
Range: Function:
0.00 %
*
[0.00 - 100.00
%]
Set the output frequency transferred to
the output terminal 29 when the terminal
is configured as 'Bus Controlled' in
5-63 Terminal 29 Pulse Output Variable
[45].
This parameter only applies for FC 302.
5-96 Pulse Out #29 Timeout Preset
Range: Function:
0.00 %
*
[0.00 -
100.00 %]
Set the output frequency transferred to
the output terminal 29 when the terminal
is configured as 'Bus Ctrl Timeout' in
5-63 Terminal 29 Pulse Output Variable [48].
And a timeout is detected.
This parameter only applies for FC 302.
5-97 Pulse Out #X30/6 Bus Control
Range: Function:
0.00 %
*
[0.00 - 100.00
%]
Set the output frequency transferred to
the output terminal X30/6 when the
terminal is configured as 'Bus Controlled'
in 5-66 Terminal X30/6 Pulse Output
Variable, Terminal X30/6 Pulse Output
Variable [45].
5-98 Pulse Out #X30/6 Timeout Preset
Range: Function:
0.00 %
*
[0.00 - 100.00
%]
Set the output frequency transferred to
the output terminal X30/6 when the
terminal is configured as 'Bus Ctrl
Timeout' in 5-66 Terminal X30/6 Pulse
Output Variable [48]. And a timeout is
detected.
