5-40 Function Relay
Array [9]
(Relay 1 [0], Relay 2 [1], Relay 3 [2] (MCB 113), Relay 4 [3] (MCB 113),
Relay 5 [4] (MCB 113), Relay 6 [5] (MCB 113), Relay 7 [6] (MCB 105),
Relay 8 [7] (MCB 105), Relay 9 [8] (MCB 105))
Option: Function:
the output will go high. Otherwise, it
will be low.
[74] Logic rule 4 See par. group 13-4* (Smart Logic
Control). If Logic Rule 4 in SLC is TRUE,
the output will go high. Otherwise, it
will be low.
[75] Logic rule 5 See par. group 13-4* (Smart Logic
Control). If Logic Rule 5 in SLC is TRUE,
the output will go high. Otherwise, it
will be low.
[80] SL digital output A See 13-52 SL Controller Action. Output
A is low on Smart Logic Action [32].
Output A is high on Smart Logic
Action [38].
[81] SL digital output B See 13-52 SL Controller Action. Output
B is low on Smart Logic Action [33].
Output B is high on Smart Logic
Action [39].
[82] SL digital output C See 13-52 SL Controller Action. Output
C is low on Smart Logic Action [34].
Output C is high on Smart Logic
Action [40].
[83] SL digital output D See 13-52 SL Controller Action. Output
D is low on Smart Logic Action [35].
Output D is high on Smart Logic
Action [41]
[84] SL digital output E See 13-52 SL Controller Action. Output
E is low on Smart Logic Action [36].
Output E is high on Smart Logic
Action [42].
[85] SL digital output F See 13-52 SL Controller Action. Output
F is low on Smart Logic Action [37].
Output F is high on Smart Logic
Action [43].
[120] Local ref active Output is high when 3-13 Reference
Site = [2] Local or when 3-13 Reference
Site = [0] Linked to hand auto at the
same time as the LCP is in hand on
mode.
5-40 Function Relay
Array [9]
(Relay 1 [0], Relay 2 [1], Relay 3 [2] (MCB 113), Relay 4 [3] (MCB 113),
Relay 5 [4] (MCB 113), Relay 6 [5] (MCB 113), Relay 7 [6] (MCB 105),
Relay 8 [7] (MCB 105), Relay 9 [8] (MCB 105))
Option: Function:
Reference site
set in
3-13 Reference
Site
Local
referen
ce
active
[120]
Remote
reference
active
[121]
Reference site:
Local
3-13 Reference
Site [2]
10
Reference site:
Remote
3-13 Reference
Site [1]
01
Reference site:
Linked to Hand/
Auto
Hand 1 0
Hand -> off 1 0
Auto -> off 0 0
Auto 0 1
[121] Remote ref active Output is high when 3-13 Reference
Site = Remote [1] or Linked to hand/
auto [0] while the LCP is in [Auto on]
mode. See above.
[122] No alarm Output is high when no alarm is
present.
[123] Start command activ Output is high when the start
command high (i.e., via digital input,
bus connection or [Hand on] or [Auto
on]), and a stop was the last
command.
[124] Running reverse Output is high when the adjustable
frequency drive is running counter
clockwise (the logical product of the
status bits ‘running’ AND ‘reverse’).
[125] Drive in hand mode Output is high when the adjustable
frequency drive is in hand on mode
(as indicated by the LED light above
[Hand on]).
[126] Drive in auto mode Output is high when the adjustable
frequency drive is in ‘Auto’ mode (as
indicated by LED on above [Auto On]).
[189] External Fan Control
Parameter Descriptions FC 300 Programming Guide
3-60 MG.33.MA.22 - VLT
®
is a registered Danfoss trademark
3
3
