UL Compliance
Alternate Fuses 200-240 V drives 1/3 hp
to 30 hp (0.25 kW - 22 kW)
FC 300 Bussmann Bussmann Bussmann Bussmann Bussmann Bussmann
kW Type RK1 Type J Type T Type CC Type CC Type CC
K25-K37 KTN-R05 JKS-05 JJN-06 FNQ-R-5 KTK-R-5 LP-CC-5
K55-1K1 KTN-R10 JKS-10 JJN-10 FNQ-R-10 KTK-R-10 LP-CC-10
1K5 KTN-R15 JKS-15 JJN-15 FNQ-R-15 KTK-R-15 LP-CC-15
2K2 KTN-R20 JKS-20 JJN-20 FNQ-R-20 KTK-R-20 LP-CC-20
3K0 KTN-R25 JKS-25 JJN-25 FNQ-R-25 KTK-R-25 LP-CC-25
3K7 KTN-R30 JKS-30 JJN-30 FNQ-R-30 KTK-R-30 LP-CC-30
5K5 KTN-R50 KS-50 JJN-50 - - -
7K5 KTN-R60 JKS-60 JJN-60 - - -
11K KTN-R80 JKS-80 JJN-80 - - -
15K-18K5 KTN-R125 JKS-150 JJN-125 - - -
FC 300 SIBA Littel fuse
Ferraz-
Shawmut
Ferraz-
Shawmut
kW Type RK1 Type RK1 Type CC Type RK1
K25-K37 5017906-005 KLN-R05 ATM-R05 A2K-05R
K55-1K1 5017906-010 KLN-R10 ATM-R10 A2K-10R
1K5 5017906-016 KLN-R15 ATM-R15 A2K-15R
2K2 5017906-020 KLN-R20 ATM-R20 A2K-20R
3K0 5017906-025 KLN-R25 ATM-R25 A2K-25R
3K7 5012406-032 KLN-R30 ATM-R30 A2K-30R
5K5 5014006-050 KLN-R50 - A2K-50R
7K5 5014006-063 KLN-R60 - A2K-60R
11K 5014006-080 KLN-R80 - A2K-80R
15K-18K5 2028220-125 KLN-R125 - A2K-125R
Alternate Fuses 200-240 V drives 30 hp
to 60 hp (22 kW - 45 kW)
FC 300 Bussmann SIBA Littel fuse
Ferraz-
Shawmut
kW Type JFHR2 Type RK1 JFHR2 JFHR2
22K FWX-150 2028220-150 L25S-150 A25X-150
30K FWX-200 2028220-200 L25S-200 A25X-200
37K FWX-250 2028220-250 L25S-250 A25X-250
KTS fuses from Bussmann may substitute for KTN in 240 V adjustable frequency drives.
FWH fuses from Bussmann may substitute for FWX in 240 V adjustable frequency drives.
JJS fuses from Bussmann may substitute for JJN in 240 V adjustable frequency drives.
KLSR fuses from LITTEL FUSE may substitute for KLNR in 240 V adjustable frequency
drives.
L50S fuses from LITTEL FUSE may substitute for L25S fuses in 240 V adjustable fre-
quency drives.
A6KR fuses from FERRAZ SHAWMUT may substitute for A2KR in 240 V adjustable fre-
quency drives.
A50X fuses from FERRAZ SHAWMUT may substitute for A25X in 240 V adjustable fre-
quency drives.
VLT
®
AutomationDrive FC 300 Instruction
Manual
3. How to Install
MG.33.A9.22 - VLT is a registered Danfoss trademark 29
3

Danfoss FC 301 Specifications

General

Type	AC Drive
Output frequency	0-1000 Hz
Enclosure rating	IP20, IP21, IP55
Control method	Sensorless vector control
Communication options	RS-485, CANopen, Profibus DP
Ambient temperature	-10°C to +50°C
Supply voltage	200-240 V, 380-500 V, 525-690 V
Protection class	IP20, IP21, IP55
Cooling method	Forced air
Relative humidity	5% to 95% (non-condensing)
Storage temperature range	-25 to 70 °C (-13 to 158 °F)
