Alternate Fuses 380-500 V drives 1/2 hp
to 75 hp (0.37 kW - 55 kW)
FC 300 Bussmann Bussmann Bussmann Bussmann Bussmann Bussmann
kW Type RK1 Type J Type T Type CC Type CC Type CC
K37-1K1 KTS-R6 JKS-6 JJS-6 FNQ-R-6 KTK-R-6 LP-CC-6
1K5-2K2 KTS-R10 JKS-10 JJS-10 FNQ-R-10 KTK-R-10 LP-CC-10
3K0 KTS-R15 JKS-15 JJS-15 FNQ-R-15 KTK-R-15 LP-CC-15
4K0 KTS-R20 JKS-20 JJS-20 FNQ-R-20 KTK-R-20 LP-CC-20
5K5 KTS-R25 JKS-25 JJS-25 FNQ-R-25 KTK-R-25 LP-CC-25
7K5 KTS-R30 JKS-30 JJS-30 FNQ-R-30 KTK-R-30 LP-CC-30
11K KTS-R40 JKS-40 JJS-40 - - -
15K KTS-R50 JKS-50 JJS-50 - - -
18K KTS-R60 JKS-60 JJS-60 - - -
22K KTS-R80 JKS-80 JJS-80 - - -
30K KTS-R100 JKS-100 JJS-100 - - -
37K KTS-R125 JKS-150 JJS-150 - - -
45K KTS-R150 JKS-150 JJS-150 - - -
FC 300 SIBA Littel fuse
Ferraz-
Shawmut
Ferraz-
Shawmut
kW Type RK1 Type RK1 Type CC Type RK1
K37-1K1 5017906-006 KLS-R6 ATM-R6 A6K-6R
1K5-2K2 5017906-010 KLS-R10 ATM-R10 A6K-10R
3K0 5017906-016 KLS-R15 ATM-R15 A6K-15R
4K0 5017906-020 KLS-R20 ATM-R20 A6K-20R
5K5 5017906-025 KLS-R25 ATM-R25 A6K-25R
7K5 5012406-032 KLS-R30 ATM-R30 A6K-30R
11K 5014006-040 KLS-R40 - A6K-40R
15K 5014006-050 KLS-R50 - A6K-50R
18K 5014006-063 KLS-R60 - A6K-60R
22K 2028220-100 KLS-R80 - A6K-80R
30K 2028220-125 KLS-R100 - A6K-100R
37K 2028220-125 KLS-R125 - A6K-125R
45K 2028220-160 KLS-R150 - A6K-150R
Alternate Fuses 380-500 V drives 75 hp
to 600 hp (55 kW - 450 kW)
FC 300 Bussmann Bussmann Bussmann Bussmann
kW JFHR2 Type H Type T JFHR2
55K FWH-200 - - -
75K FWH-250 - - -
90K FWH-300 NOS-300 JJS-300 170M3017
P110 FWH-350 NOS-350 JJS-350 170M3018
P132 FWH-400 NOS-400 JJS-400 170M4012
P160 FWH-500 NOS-500 JJS-500 170M4014
P200 FWH-600 NOS-600 JJS-600 170M4016
P250 - - - 170M4017
170M5013
P315 - - - 170M6013
P355 - - - 170M6013
P400 - - - 170M6013
3. How to Install
VLT
®
AutomationDrive FC 300 Instruction
Manual
30 MG.33.A9.22 - VLT is a registered Danfoss trademark
3

Danfoss FC 301 Specifications

General

Type	AC Drive
Output frequency	0-1000 Hz
Enclosure rating	IP20, IP21, IP55
Control method	Sensorless vector control
Communication options	RS-485, CANopen, Profibus DP
Ambient temperature	-10°C to +50°C
Supply voltage	200-240 V, 380-500 V, 525-690 V
Protection class	IP20, IP21, IP55
Cooling method	Forced air
Relative humidity	5% to 95% (non-condensing)
Storage temperature range	-25 to 70 °C (-13 to 158 °F)
