Danfoss FC 301

FC 300 SIBA Littel fuse
Ferraz-
Shawmut
Ferraz-
Shawmut
kW Type RK1 JFHR2 JFHR2 JFHR2
55K 2028220-200 L50S-225 - A50-P225
75K 2028220-250 L50S-250 A50-P250
90K 2028220-315 L50S-300 - A50-P300
P110 2028220-315 L50S-350 - A50-P350
P132 206xx32-400 L50S-400 - A50-P400
P160 206xx32-500 L50S-500 - A50-P500
P200 206xx32-600 L50S-600 - A50-P600
P250 2061032.700 - 6.9URD31D08A07
00
-
P315 2063032.900 - 6.9URD33D08A09
00
-
P355 2063032.900 - 6.9URD33D08A09
00
-
P400 2063032.900 - 6.9URD33D08A09
00
-
Ferraz-Shawmut A50QS fuses may be substituted for A50P fuses.
170M fuses shown from Bussmann use the -/80 visual indicator. –TN/80 Type T, -/110
or TN/110 Type T indicator fuses of the same size and amperage may be substituted.
Alternate Fuses 550 - 600V drives 1 hp
to 10 hp (0.75 kW - 7.5 kW)
FC 300 Bussmann Bussmann Bussmann Bussmann Bussmann Bussmann
kW Type RK1 Type J Type T Type CC Type CC Type CC
K75-1K5 KTS-R-5 JKS-5 JJS-6 FNQ-R-5 KTK-R-5 LP-CC-5
2K2-4K0 KTS-R10 JKS-10 JJS-10 FNQ-R-10 KTK-R-10 LP-CC-10
5K5-7K5 KTS-R20 JKS-20 JJS-20 FNQ-R-20 KTK-R-20 LP-CC-20
FC 300 SIBA Littel fuse
Ferraz-
Shawmut
kW Type RK1 Type RK1 Type RK1
K75-1K5 5017906-005 KLSR005 A6K-5R
2K2-4K0 5017906-010 KLSR010 A6K-10R
5K5-7K5 5017906-020 KLSR020 A6K-20R
VLT
®
AutomationDrive FC 300 Instruction
Manual
3. How to Install
MG.33.A9.22 - VLT is a registered Danfoss trademark 31
3
