7-0* Speed PID Ctrl. 7-00 Speed PID Feedback Source null All set-ups FALSE - Uint8 7-02 Speed PID Proportional Gain ExpressionLimit All set-ups TRUE -3 Uint16
7-03 Speed PID Integral Time ExpressionLimit All set-ups TRUE -4 Uint32
7-04 Speed PID Differentiation Time ExpressionLimit All set-ups TRUE -4 Uint16
7-05 Speed PID Diff. Gain Limit 5.0 N/A All set-ups TRUE -1 Uint16
7-06 Speed PID Lowpass Filter Time 10.0 ms All set-ups TRUE -4 Uint16
7-08
Speed PID Feed Forward Factor 0 % All set-ups FALSE 0 Uint16
7-2* Process Ctrl. Feedb 7-20 Process CL Feedback 1 Resource [0] No function All set-ups TRUE - Uint8 7-22 Process CL Feedback 2 Resource [0] No function All set-ups TRUE - Uint8
7-3* Process PID Ctrl.
7-30 Process PID Normal/Inverse Control [0] Normal All set-ups TRUE - Uint8 7-31 Process PID Anti Windup [1] On All set-ups TRUE - Uint8 7-32 Process PID Controller Start Value 0 RPM All set-ups TRUE 67 Uint16
7-33 Process PID Proportional Gain 0.01 N/A All set-ups TRUE -2 Uint16
7-34 Process PID Integral Time 10000.00 s All set-ups TRUE -2 Uint32
7-35 Process PID Differentiation Time 0.00 s All set-ups TRUE -2 Uint16
7-36 Process PID Differentiation Gain Limit 5.0 N/A All set-ups TRUE -1 Uint16
7-38 Process PID Feed Forward Factor 0 % All set-ups TRUE 0 Uint16
7-39 On Reference Bandwidth 5 % All set-ups TRUE 0 Uint8
4.3.8. 7-** Controllers
