Danfoss FC 301

Par. No. #
Parameter description Default value 4-set-up FC 302
only
Change during
operation
Conver-
sion index
Type
8-0* General Settings 8-01 Control Site [0] Digital and ctrl. word All set-ups TRUE - Uint8 8-02 Control Word Source null All set-ups TRUE - Uint8
8-03 Control Word Timeout Time 1.0 s 1 set-up TRUE -1 Uint32
8-04 Control Word Timeout Function [0] Off 1 set-up TRUE - Uint8
8-05 End-of-Timeout Function [1] Resume set-up 1 set-up TRUE - Uint8
8-06 Reset Control Word Timeout [0] Do not reset All set-ups TRUE - Uint8
8-07
Diagnosis Trigger [0] Disable 2 set-ups TRUE - Uint8
8-1* Ctrl. Word Settings 8-10 Control Word Profile [0] FC profile All set-ups TRUE - Uint8 8-13 Configurable Status Word STW [1] Profile Default All set-ups TRUE - Uint8 8-3* FC Port Settings 8-30 Protocol [0] FC 1 set-up TRUE - Uint8 8-31 Address 1 N/A 1 set-up TRUE 0 Uint8 8-32 FC Port Baud Rate [2] 9600 Baud 1 set-up TRUE - Uint8
8-35 Minimum Response Delay 10 ms All set-ups TRUE -3 Uint16
8-36 Max Response Delay 5000 ms 1 set-up TRUE -3 Uint16
8-37
Max Inter-Char Delay 25 ms 1 set-up TRUE -3 Uint16
8-4* FC MC protocol set 8-40 Telegram selection [1] Standard telegram 1 2 set-ups TRUE - Uint8 8-5* Digital/Bus 8-50 Coasting Select [3] Logic OR All set-ups TRUE - Uint8 8-51 Quick Stop Select [3] Logic OR All set-ups TRUE - Uint8
8-52 DC Brake Select [3] Logic OR All set-ups TRUE - Uint8
8-53 Start Select [3] Logic OR All set-ups TRUE - Uint8
8-54 Reverse Select [3] Logic OR All set-ups TRUE - Uint8
8-55 Set-up Select [3] Logic OR All set-ups TRUE - Uint8
8-56
Preset Reference Select [3] Logic OR All set-ups TRUE - Uint8
8-9* Bus Jog 8-90 Bus Jog 1 Speed 100 RPM All set-ups TRUE 67 Uint16 8-91 Bus Jog 2 Speed 200 RPM All set-ups TRUE 67 Uint16
4.3.9. 8-** Comm. and Options
4. How to Program
VLT
®
AutomationDrive FC 300 Instruction
Manual
66 MG.33.A9.22 - VLT is a registered Danfoss trademark
4
