FC 300 Instruction Manual
How to Program
Parameter lists
Change s during operation
"TRUE" means that the parameter can be changed while the adjustable frequency drive is in operation
and "FA LSE" means that the it m u st be stopped before a change can be made.
4
-Set-up
All set-up’: the parameters can be set individually in each of the four set-ups, i.e. one
single parameter can have four different da ta values.
’1 set-up ’: data value will be the same in all set-ups.
C
onversion index
This number refers to a conversion figure used whe n writing or reading by means of a variable frequency drive.
Conv. index 100 67 6 5 4 3 2 1 0 -1 -2 -3 -4 -5 -6
Conv. factor 1 1/60 1000000 100000 10000 1000 100 10 1 0.1 0.01 0.001 0.0001 0.00001 0.000001
Data type Description Type
2 Integer 8 Int8
3 Integer 16 Int16
4
Integer 32 Int32
5 Unsigned 8 Uint8
6
Unsigned 16 Uint16
7 Unsigned 32 Uint32
9
Visible String VisStr
33 Normalized value 2 bytes N2
35
Bit sequence of 1 6 boolean variables V2
54 Time difference w/o date TimD
See the FC 300 Design Guid e for further information a bout data types 33, 35 and 54.
*
default setting ()display text []value for use in communication via serial communication port
45
MG.33.A
