Page #50 background imageLoading...
Page #50 background image
4.13 Parameter Group 16: Data Readouts
16-00 Control Word
Range: Function:
0* [0-65535] View latest valid control word sent to frequency
converter via serial communication port.
16-01 Reference [Unit]
Range: Function:
0.000* [-4999.000-4999.000] View total remote reference. Total
reference is sum of pulse, analog,
preset, LCP potentiometer, local
bus and freeze reference.
16-02 Reference %
Range: Function:
0.0* [-200.0-200.0%] View total remote reference in percent.
Total reference is sum of pulse, analog,
preset, LCP potentiometer, local bus and
freeze reference.
16-03 Status Word
Range: Function:
0* [0-65535] View status word sent to frequency converter via
serial communication port.
16-05 Main Actual Value %
Range: Function:
0.00* [-100.00-100.00%] View two-byte word sent with status
word to bus Master reporting main
actual value.
16-09 Custom Readout
Range: Function:
0.00* [0.00-9999.00%]
Customized readout based on the
settings of 0-31 Custom Readout Min
Scale, 0-32 Custom Readout Max Scale
and 4-14 Motor Speed High Limit
4.13.1 16-1* Motor Status
16-10 Power [kW]
Range: Function:
0 kW* [0-99 kW] View output power in kW.
16-11 Power [hp]
Range: Function:
0 hp [0-99 hp ] View output power in hp.
16-12 Motor Voltage
Range: Function:
0.0* [0.0-999.9 V] View motor phase voltage.
16-13 Frequency
Range: Function:
0.0 Hz* [0.0-400.0 Hz] View output frequency in Hz.
16-14 Motor Current
Range: Function:
0.00 A* [0.00-655 A] View motor phase current.
16-15 Frequency [%]
Range: Function:
0.00* [-100.00-100.00%] View a two-byte word reporting actual
motor frequency as a percentage of
4-14 Motor Speed High Limit
16-18 Motor Thermal
Range: Function:
0%* [0-100%] View calculated thermal motor load as
percentage of estimated thermal motor load.
4.13.2 16-3* Drive Status
16-30 DC Link Voltage
Range: Function:
0 V* [0-10000 V] View DC-link voltage.
16-34 Heat Sink Temp.
Range: Function:
0*
[0-255°C]
View heat sink temperature of frequency
converter.
16-35 Inverter Thermal
Range: Function:
0%* [0-100%] View calculated thermal load on frequency
converter in relation to estimated thermal load
on frequency converter.
16-36 Inv. Nom. Current
Range: Function:
0.00 A* [0.01-655A] View continuous nominal inverter current.
16-37 Inv. Max. Current
Range: Function:
0.00 A* [0.1-655A] View intermittent maximum inverter current
(150%).
16-38 SL Controller State
Range: Function:
0* [0-255] View number of active SLC state.
4.13.3 16-5* Ref. & Feedb.
16-50 External Reference
Range: Function:
0.0%* [-200.0-200.0%] View sum of all external references in
percent.
Parameter Descriptions
VLT
®
Micro Drive FC 51 Programming Guide
48 MG02C602 - VLT
®
is a registered Danfoss trademark
44
