Page #125 background image
FCM 300 Series
MG.03.B6.2G - VLT is a registered Danfoss trademark
Range/number
Function of settings HVAC setting Parameter No.
Display line 1.3 HP Power HP Parameter 012
Operating state at power up, local Auto restart Parameter 019
Torque characteristics Variable torque high Parameter 101
Slip compensation -500 - +500% 0% Parameter 136
Min. output frequency 0 Hz - f
MAX
6.0 Hz Parameter 201
Min. reference -100,000.000 - Ref
MAX
6.000 Hz Parameter 204
Max. reference Ref
MIN
- 100,000.000 60.000 Hz Parameter 205
Ramp-up time 0.15 - 3600.00 sec. 60.00 sec. Parameter 207
Ramp-down time 0.15 - 3600.00 sec. 60.00 sec. Parameter 208
Jog ramp time 0.15 - 3600.00 sec. 60.00 sec. Parameter 211
Reference function External/preset Parameter 214
Term. 1, analogue input current Reference Parameter 331
Term. 1, min. scaling 0.0 - 20.0 mA 4.0 mA Parameter 336
Term. 9, output functions Motor running Parameter 340
Reset function Automatic reset x 10 Parameter 405
Max. feedback FB
LOW
- 100,000.000 100.000 Parameter 415
PID proportional gain 0.00 - 10.00 0.3 Parameter 440
PID integral time 0.01 - 9999 sec. 20 sec. Parameter 441
Flying start OK - both directions Parameter 445
Switching pattern 60° AVM Parameter 446
Operation and DisplayOperation and Display
Operation and DisplayOperation and Display
Operation and Display
Load and MotorLoad and Motor
Load and MotorLoad and Motor
Load and Motor
References and LimitsReferences and Limits
References and LimitsReferences and Limits
References and Limits
Inputs and OutputsInputs and Outputs
Inputs and OutputsInputs and Outputs
Inputs and Outputs
Special FunctionsSpecial Functions
Special FunctionsSpecial Functions
Special Functions
Special Parameter Settings for HVAC Products
Range/number
Function of settings Industrial setting Parameter No.
Display line 1.3 HP Power [HP] Parameter 012
Max. reference Ref
MIN
- 100,000.000 60.000 Parameter 205
Term. 1, analogue input current Reference Parameter 331
Term. 1, min. scaling 0.0 - 20.0 mA 4.0 mA Parameter 336
Term. 9, output functions Motor running Parameter 340
Max. feedback FB
LOW
- 100,000.000 100.000 Parameter 415
PID proportional gain 0.00 - 10.00 0.3 Parameter 440
PID integral time 0.01 - 9999 sec. 20 sec. Parameter 441
Operation and DisplayOperation and Display
Operation and DisplayOperation and Display
Operation and Display
References and LimitsReferences and Limits
References and LimitsReferences and Limits
References and Limits
Inputs and OutputsInputs and Outputs
Inputs and OutputsInputs and Outputs
Inputs and Outputs
Special FunctionsSpecial Functions
Special FunctionsSpecial Functions
Special Functions
Special Parameter Settings for Industrial Products
