339 Terminal 2, max. scaling
(AI 2 SCALE HIGH)
Settings:
0.0 - 10.0 V [0 - 100]
★ 10.0 V [100]
Function:
This parameter is used for setting the signal value
that corresponds to the maximum reference value
set in parameter 205.
Description of choice:
Set the desired voltage value.
340 Terminal 9, output functions (OUTPUT FUNC.)
Settings:
✭ No function (NO OPERATION) [0]
Ready signal (UNIT READY) [1]
Enable, no warning (ENABLE/NO WARNING) [2]
H,I Running (MOTOR RUNNING) [3]
Running, no warning (RUNNING NO WARNING) [4]
Running on reference, no warning (RUNNING ON REFERENCE) [5]
Fault (FAULT) [6]
Fault or warning (FAULT OR WARNING) [7]
Current limit (CURRENT LIMIT) [8]
Thermal warning (THERMAL WARNING) [9]
Reversing (REVERSE) [10]
Off 123 (OFF 123 RELAY) [11]
Actual frequency 0-20 mA (0-FMAX = 0-20 mA) [12]
Actual frequency 4-20 mA (0-FMAX = 4-20 mA) [13]
Reference
MIN
- reference
MAX
: 0-20 mA (REF MIN-MAX =0-20 mA) [14]
Reference
MIN
- reference
MAX
: 4-20 mA (REF MIN-MAX =4-20 mA) [15]
Feedback
MIN
- feedback
MAX
: 0-20 mA (FB MIN-MAX =0-20 mA) [16]
Feedback
MIN
- feedback
MAX
: 4-20 mA (FB MIN-MAX =4-20 mA) [17]
Actual current 0-20 mA (0-IMAX = 0-20 mA) [18]
Actual current 4-20 mA (0-IMAX = 4-20 mA) [19]
Mechanical brake (MECHANICAL BRAKE) [20]
Function:
This output can act both as a digital and an analog
output. If used as a digital output (data value [0]-
[11]), a 24 V DC signal is transmitted; if used as an
analog output (DATA VALUE [12]-[20]) either a 0-20
mA signal, or a 4-20 mA signal output.
Description of choice:
Unit Ready signal, the FCM 300 is ready for use.
Enable/no warning, the FCM 300 is ready for use;
no start or stop command has been given (start/
disable). No warning.
Motor Running, the output frequency is higher than
0.1 Hz. A start command has been given.
Running no warning, the output frequency is higher
than 0.1 Hz. A start command has been given. No
warning.
Running on reference, no warning, speed according
to reference. No warning.
Fault, output is activated by alarm.
Fault or warning, the output is activated by alarm or
warning.
Parameter Group 3: Inputs and outputs
11-6
338 Terminal 2, min. scaling
(AI 2 SCALE LOW)
Settings:
0.0 - 10.0 V [0 - 100]
★ 0.0 V [0]
Function:
This parameter is used for setting the signal value
that corresponds to the minimum reference value
set in parameter 204.
Description of choice:
Set the desired voltage value.
