FCM 300 Series
MG.03.B6.2G - VLT is a registered Danfoss trademark
Off 123 relay, if Profidrive [0] has been selected in
parameter 512, the output is activated. If either
OFF1, OFF2 or OFF3 (bit in the control word) is logic
'1'.
0-f
MAX
(parameter 202) ⇒ 0-20 mA and
0-f
MAX
(parameter 202) ⇒ 4-20 mA
Reference
MIN
- Reference
MAX
: 0-20 mA and
Reference
MIN
- Reference
MAX
: 4-20 mA
Feedback
LOW
- Feedback
HIGH
: 0-20 mA and
Feedback
LOW
- Feedback
HIGH
: 4-20 mA
0-I
VLT, MAX
⇒ 0-20 mA and
0-I
VLT, MAX
⇒ 4-20 mA
Mechanical brake, enables control of an optional
external mechanical brake (see also parameter 138
and 139).
Parameter Group 3: Inputs and Outputs
11-7
Current limit, the current limit in parameter 221 has
been exceeded.
Thermal warning, above the temperature limit in the
frequency converter.
Reverse. Logic '1' = relay activated, 24 V DC on the
output when the direction of rotation of the motor is
clockwise. Logic '0' = relay not activated, no signal
on the output, when the direction of rotation of the
motor is counter-clockwise.
✭ = General factory setting - also applying to spare part unit,
HH
HH
H = HVAC setting,
II
II
I = Industrial setting, ( ) = parameter
window text. [ ] = value for use in communication via serial communication port
