1.8 Overview of Installation Area
PELV (Safe to touch)
1 RS-485 interface
2 Option slot A (can be used for GSM option, optional sensor interface, or PLA option)
3 Ethernet interface
4 Option slot A (can be used for GSM option, optional sensor interface, or PLA option)
Live Part
5 PV connection area
6 Communication board
7AC terminal
Other
8 Security screw position
9PV load switch
10 Security screw position
Illustration 1.3 Overview of Installation Area
Introduction
6 L00410568-02_02 / Rev. date: 2013-12-10
1
