Installation Guide Danfoss Link™ HC
GB
Danfoss Link™ is a wireless control system for a variety of heating systems.
The Danfoss Link™ HC (Hydronic Controller) is a part of this system allowing wireless control of
manifolds for water based floor heating/cooling.
Inputs:
Not in use
Away Function (external ON/OFF switch)
Heating/Cooling (external ON/OFF switch)
Front
cover
release
External
Antenna
Output LEDs
Install / Link TestOutput connections
Pump relayBoiler relay
Introduction
The Danfoss Link™ HC should always be mounted in an horizontal upright position.
1: Mounting on wall
1. Remove front and side covers and mount with screws and wall plugs.
2: Mounting on DIN-rail
1. Mount DIN-rail parts. 2. Click on DIN-rail. 3. Release from DIN-rail.
Mounting
To Next Page
