Option 90 - De ne remote sensor type, “A” models only

This allows type of remote sensor input type to be

de ned. Press + until Option 90 is displayed, use V

and Λ to select required setting.

Setting 0 No remote sensor  tted (Factory setting)

Setting 1 Remote room or duct sensor  tted, internal sensor disabled

Setting 2 Remote limit sensor  tted, refer to option 93 to de ne set-point

Setting 3 Con gured as digital input for window, card reader or

teleswitch, refer to option 94 to de ne o/c or s/c.

Option 93 - Set limit sensor set-point, “A” models only,

(option 90 set to 2)

This allows the thermostat limit sensor to be set,

typical application is  oor htg. Press + until Option

93 is displayed, use V and Λ to select required

setting. If the temperature sensed by the limit sensor exceeds the limit

setting the output will be turned o untill the temperature has dropped

by 2°C “F10” will  ash in the display.

Setting Any value between 20 - 50°C (Factory setting is 27°C)

Option 94 - Con gure digital input switch type, “A” models only,

(option 90 set to 3)

This allows switch type of digital input to be

con gured. Press + until Option 94 is displayed, use

V and Λ to select required setting.

Setting 0 Contacts NC, open circuit contact to force unit into

thermostat mode, short circuit contacts to return to normal

operation

Setting 1 Contacts NO, short circuit contacts to force unit into

thermostat mode, open circuit contacts to return to normal

operation (Factory setting)

Option 81 - Thermstat calibration bias

This allows the thermostat calibration to be biased by

up to ±1.5°K. Press + until Option 81 is displayed, use V

and Λ to select required setting.

Setting Any value between ±1.5 (Factory setting is 0°C)
