Danfoss TP5001 Range Installation Guide

TP5001
4
GR
TR
LV
LT
UA
RU
GB
Thermostat features TP5001 (A) TP5001-RF TP5001M (A)
Power supply
2 x AA/MN1500/LR
alkaline cells
230V, ±15%,
50Hz
Memory back-up Retained for life of product
Temperature Range
Sensing
5-30°C
Factory set calendar clock Automatic summer/winter time change
Switching action of
output relay
3(1)A,
10-230V
N/A
3(1)A, 10-230V,
Type 1B
Transmission frequency
(RF models)
N/A 433.92MHz N/A
Transmission range
(RF models)
N/A 30m max. N/A
Remote sensor inputs
(A models only)
Can be set by installer for remote temperature
sensor, limit sensor, window contact or telephone
activated switch contacts
Dimensions (mm) 110 wide, 88 high, 28 deep
Design standard EN60730-2-9 (EN300220 for RF)
Rated impulse voltage 2.5kV
Ball hardness test 75°C
Control pollution
situation
Degree 2
Temperature accuracy ±1°C
Time accuracy ±1 min. per month
1.0 Installation Guide
2.0 System Overview
Please Note:
This product should only be installed by a quali ed electrician or
competent heating installer and should be in accordance with the
current edition of the IEEE wiring regulations.

Danfoss TP5001 Range Specifications

General

Control Mode	On/Off
Accuracy	±0.5°C
Protection Class	IP30
Type	Room Thermostat
Power Supply	230V AC
Temperature Range	5°C to 30°C
Mounting	Wall Mounted
