Danfoss VLT 3500 Series User Manual

8
VLT type 3575 3600 3625 3650 3700 3750 3800
Output current I
VLT,N
[A] 105 139 168 205 243 302 368
I
VLT, MAX
(60 s) [A] 116 153 185 226 267 332 405
Output S
VLT, N
[kVA] 73 96 116 142 168 209 255
Typical shaft output P
VLT, N
[HP] 75 100 125 150 200 250 300
Max. cable cross-section [AWG] 2/0 2/0 500mcm 500mcm 500mcm 2x250mcm 2x250mcm
Max. motor cable length [feet] 1000 (unshielded)*
Output voltage V
M
[%] 1-100, of AC line voltage
Output frequency f
M
[Hz] 0-120
Rated motor voltage V
M, N
[V] 380/400/415/440/460/500
Rated motor frequency f
M, N
[Hz] 50/60/87/100
Thermal protection during operation Integrated thermal motor protection (electronic); thermistor to DIN44081
Switching on output Unlimited (frequent switching may cause cut-out)
Ramp times [s] 0.1-3600
VLT type 3575 3600 3625 3650 3700 3750 3800
Max. input current I
L, N
[A] 103.3 138.4 167.2 201.7 241.9 293.3 366.3
IL,MAX (60S) [A] 116 153 185 226 267 332 405
Max. cable cross-section [AWG] 250mcm 250mcm 2x250mcm 2x250mcm 2x250mcm 2x250mcm 2x250mcm
Max. pre-fuses
1)
[A] 150 150 250 250 300 450 500
Supply voltage [V] 3 x 380/400/415/440/460/500 ±10%
Supply frequency [Hz] 50/60
Power factor / cos 0.9/1.0
Efficiency 0.96 at 100% load
Switching on input times/min. 1
Radio noise, cable borne With option: EN55011, class B, group 1, VDE 0875 part 3, curve G
VLT type 3575 3600 3625 3650 3700 3750 3800
Weight (lbs) and NEMA 1 (IP21) 323 323 464 464 484 673 673
enclosure type NEMA 12 (IP 54) 323 323 464 464 484 673 673
Power loss Front 529 713 910 1091 1503 1812 2209
at max. load [W] Cooling rib 1074 1447 1847 2216 3051 3679 4485
Vibration test [g] 0.7
Relative humidity [%] VDE 0160 5.2.1.2.
Ambient temperature [°C] –10 ➔ +40, operation at full load
1)
–30/25 ➔ +65/70, storage/transport
Adjustable frequency drive protection Protection against grounding and short-circuiting
EMC standards Emission EN 50011, VDE 0875 part 3
Immunity EN 50082-2, IEC 801-2, IEC 801-3, IEC 801-4, IEC 801-5, VDE 0160, SEN 361503
* If shielded cable is to be used, consult Danfoss for cable length.
1) In the range –10 to 0°C, the equipment can start and run; however, the display values and certain operating characteristics will
not fulfill the specifications.
VLT
®
Series 3500
3 Phase, 380/400/415 Volt, Units
