Danfoss VLT 3500 Series User Manual

7
VLT type 3502 3504 3506 3508 3511 3516 3522 3532 3542 3552 3562
Output current I
VLT,N
[A] 2.6 4.8 8.2 12.6 14.4 21.7 37.9 41.4 54.0 65.0 78.0
I
VLT, MAX
(60 s) [A] 2.9 5.3 9.0 13.9 15.9 24.0 30.7 45.8 59.6 71.5 85.8
Output S
VLT, N
[kVA] 1.6 4.1 7.1 9.6 12.4 18.8 24.2 35.9 46.8 56.3 67.5
Typical shaft output P
VLT, N
[HP] 1 3 5 7.5 10 15 20 30 40 50 60
Max. cable cross-section [AWG] 12 12 12 12 6666444
Max. motor cable length [feet] 1000 (unshielded)*
Output voltage V
M
[%] 1-100, of AC line voltage
Output frequency f
M
[Hz] 0-120
Rated motor voltage V
M, N
[V] 440/460/500
Rated motor frequency f
M, N
[Hz] 50/60/87/100
Thermal protection during operation Integrated thermal motor protection (electronic); thermistor to DIN44081
Switching on output Unlimited (frequent switching may cause cut-out)
Ramp times [s] 0.1-3600
VLT type 3502 3504 3506 3508 3511 3516 3522 3532 3542 3552 3562
Max. input current I
L, N
[A] 2.6 4.8 8.2 11.1 14.4 19.6 26.0 34.8 48.6 53.0 72.0
Max. cable cross-section [AWG] 12 12 12 12 6666444
Max. pre-fuses [A] 20 20 25 25 30 30 40 50 60 100 125
Supply voltage [V] 3 phase, 440/460/500 ±10% (VDE 0160)
Supply frequency [Hz] 50/60
Power factor / cos 0.9/1.0
Efficiency 0.96 at 100% load
Switching on input times/min. 2
Radio noise, cable borne VLT type 3502-08: EN 55011, class A, gr. 1, with option class B. gr 1
(with shielded cables) VLT type 3516-62 with option: EN 55011, cl. A, 1 VDE 0875, part 3, curve N
VLT type 3502 3504 3506 3508 3511 3516 3522 3532 3542 3552 3562
Weight (lbs) Chassis (IP00) 16 16 26 31 31 ––––––
and NEMA 1 (IP 20) –––––555768108119119
enclosure type NEMA 1 (IP 21) 18 18 29 33 33 ––––––
NEMA 12 (IP 54) 24 24 31 33 33 75 81 106 139 152 152
Power loss at max. load [W] 60 130 160 200 240 281 369 880 1133 1440 1888
Vibration test [g] 0.7
Relative humidity [%] VDE 0160 5.2.1.2.
Ambient temperature [°C] –10 ➔ +40, operation at full load
1)
–30/25 ➔ +65/70, storage/transport
Adjustable frequency drive protection Protection against grounding and short-circuiting
EMC standards Emission EN 50011, VDE 0875 part 3
Immunity EN 50082-2, IEC 801-2, IEC 801-3, IEC 801-4, IEC 801-5, VDE 0160, SEN 361503
* If shielded cable is to be used, consult Danfoss for cable length.
1) In the range –10 to 0°C, the equipment can start and run; however, the display values and certain operating characteristics will
not fulfill the specifications.
VLT
®
Series 3500
3 Phase, 440/460/500 Volt, Units
