Intro-9
Ratings Table 525-600V / 525-690V
Mains supply 3 x 525-690 V: 5000 & 8000 Series
Mains supply 3 x 525-600 V: 4000 & 6000 Series
Model number
VLT 4152 VLT 4202 VLT 4252 VLT 4302 VLT 4352 VLT 4402
VLT 5122 VLT 5152 VLT 5202 VLT 5252 VLT 5302 VLT 5352
VLT 6152 VLT 6172 VLT 6222 VLT 6272 VLT 6352 VLT 6402
VLT 8152 VLT 8202 VLT 8252 VLT 8302 VLT 8352 VLT 8402
Normal overload current ratings (110 %):
Output current
Nominal [A] (525-550 V) 162 204 253 303 360 418
MAX (60 sec) [A] (525-550 V) 178 224 278 333 396 460
Nominal [A] (551-690 V) 155 192 242 290 344 400
MAX (60 sec) [A] (551-690 V) 171 211 266 319 378 440
Output
Nominal [kVA] (550 V) 154 194 241 289 343 398
Nominal [kVA] (575 V) 154 191 241 289 343 398
Nominal [kVA] (690 V) 185 229 289 347 411 478
Typical shaft output [kW] (550 V) 110 132 160 200 250 315
[HP] (575 V) 150 200 250 300 350 400
[kW] (690 V) 132 160 200 250 315 400
High overload torque (160 %):
Output current
Nominal [A] (525-550 V) 137 162 204 253 303 360
MAX (60 sec) [A] (525-550 V) 206 243 306 380 455 540
Nominal [A] (551-690 V) 131 155 192 242 290 344
MAX (60 sec) [A] (551-690 V) 197 233 288 363 435 516
Output
Nominal [kVA] (550 V) 131 154 194 241 289 343
Nominal [kVA] (575 V) 130 154 191 241 289 343
Nominal [kVA] (690 V) 157 185 229 289 347 411
Typical shaft output [kW] (550 V) 90 110 132 160 200 250
[HP] (575 V) 125 150 200 250 300 350
[kW] (690 V) 110 132 160 200 250 315
Power loss Normal overload [W] 3114 3612 4293 5155 5821 6149
Power loss High overload [W] 2665 2953 3451 4275 4875 5185
Limits and Ranges
Warning Voltage Low DC Bus V 585 585 585 585 585 585
Alarm Voltage Low DC Bus V 553 553 553 553 553 553
Warning Voltage High DC Bus V 1109 1109 1109 1109 1109 1109
Alarm Voltage High DC Bus V 1120 1120 1120 1120 1120 1120
Brake On Voltage DC Bus V 1084 1084 1084 1084 1084 1084
Brake On Voltage (Full Duty Cycle) DC Bus V 1099 1099 1099 1099 1099 1099
SMPS Start Voltage DC Bus V 508 508 508 508 508 508
SMPS Stop Voltage DC Bus V 478 478 478 478 478 478
Overcurrent Warning VLT Out 361 466 683 683 827 1038
Overcurrent Alarm (1.5 sec delay) VLT Out 361 466 683 683 827 1038
Earth Fault Alarm VLT Out 66 78 96 121 145 172
Heatsink Over Temperature Degrees C 75 80 100 100 100 100
Mains Phase Warning (5 sec delay) DC Bus Ripple VAC 70 70 70 70 70 70
Mains Phase Alarm (25 sec delay) DC Bus Ripple VAC 70 70 70 70 70 70
Fan On Low Speed Temperature Degrees C 45 45 45 45 45 45
Fan On High Sped Temperature Degrees C 50 50 50 50 50 50
Fan Off Temperature Degrees C <30 <30 <30 <30 <30 <30
Fan Voltage Low Speed Fan VAC 200 200 200 200 200 200
Fan Voltage High Speed Fan VAC 230 230 230 230 230 230
