Danfoss VLT 5000-P User Manual

VLT is a registered Danfoss trademark
Intro-10
Ratings Table 525-600V / 525-690V
Mains supply 3 x 525-690 V: 5000 & 8000 Series
Mains supply 3 x 525-600 V: 6000 Series
Model number
VLT 5402 VLT 5502 VLT 5602
VLT 6502 VLT 6602 VLT 6652
VLT 8502 VLT 8602 VLT 8652
Normal overload current ratings (110 %):
Output current Nominal [A] (525-550 V) 523 596 630
MAX (60 sec) [A] (525-550 V) 575 656 693
Nominal [A] (551-690 V) 500 570 630
MAX (60 sec) [A] (551-690 V) 550 627 693
Output
Nominal [kVA] (550 V) 498 568 600
Nominal [kVA] (575 V) 498 568 627
Nominal [kVA] (690 V) 598 681 753
Typical shaft output
[kW] (550 V) 400 450 500
[HP] (575 V) 500 600 650
[kW] (690 V) 500 560 630
High overload torque (160 %):
Output current
Nominal [A] (525-550 V) 429 523 596
MAX (60 sec) [A] (525-550 V) 644 785 894
Nominal [A] (551-690 V) 410 500 570
MAX (60 sec) [A] (551-690 V) 615 750 855
Output
Nominal [kVA] (550 V) 409 498 568
Nominal [kVA] (575 V) 408 498 568
Nominal [kVA] (690 V) 490 598 681
Typical shaft output
[kW] (550 V) 315 400 450
[HP] (575 V) 400 500 600
[kW] (690 V) 400 500 560
Power loss Normal overload [W] 7249 8727 9673
Power loss High overload [W] 5818 7671 8715
Limits and Ranges
Warning Voltage Low DC Bus V 585 585 585
Alarm Voltage Low DC Bus V 553 553 553
Warning Voltage High DC Bus V 1109 1109 1109
Alarm Voltage High DC Bus V 1130 1130 1130
Brake On Voltage DC Bus V 1084 1084 1084
Brake On Voltage (Full Duty Cycle) DC Bus V 1099 1099 1099
SMPS Start Voltage DC Bus V 508 508 508
SMPS Stop Voltage DC Bus V 478 478 478
Overcurrent Warning VLT Out 824 987 1170
Overcurrent Alarm (1.5 sec delay) VLT Out 824 987 1170
Earth Fault Alarm VLT Out 205 250 285
Heatsink Over Temperature Degrees C 75 75 75
Mains Phase Warning (5 sec delay) DC Bus Ripple VAC 70 70 70
Mains Phase Alarm (25 sec delay) DC Bus Ripple VAC 70 70 70
Fan On Low Speed Temperature Degrees C 45 45 45
Fan On High Sped Temperature Degrees C 50 50 50
Fan Off Temperature Degrees C <30 <30 <30
Fan Voltage Low Speed Fan VAC 200 200 200
Fan Voltage High Speed Fan VAC 230 230 230
