Danfoss VLT 5000-P User Manual

VLT is a registered Danfoss trademark
Intro-11
Ratings Table 525-600V / 525-690V
Mains supply 3 x 525-690 V: 5000 & 8000 Series
Mains supply 3 x 525-600 V: 4000 & 6000 Series
Model number
NA* NA* NA* VLT 4102 VLT 4122
VLT 5042 VLT 5052 VLT 5062 VLT 5072 VLT 5102
NA* NA* NA* VLT 6102 VLT 6122
VLT 8052 VLT 8062 VLT 8072 VLT 8102 VLT 8122
Normal overload current ratings (110 %):
Output current
Nominal [A] (525-550 V) 56 76 90 113 137
MAX (60 sec) [A] (525-550 V) 62 84 99 124 151
Nominal [A] (551-690 V) 54 73 86 108 131
MAX (60 sec) [A] (551-690 V) 59 80 95 119 144
Output
Nominal [kVA] (550 V) 53 72 86 108 131
Nominal [kVA] (575 V) 54 73 86 108 130
Nominal [kVA] (690 V) 65 87 103 129 157
Typical shaft output
[kW] (550 V) 37 45 55 75 90
[HP] (575 V) 50 60 75 100 125
[kW] (690 V) 45 55 75 90 110
High overload torque (160 %):
Output current Nominal [A] (525-550 V) 48 56 76 90 113
MAX (60 sec) [A] (525-550 V) 77 90 122 135 170
Nominal [A] (551-690 V) 46 54 73 86 108
MAX (60 sec) [A] (551-690 V) 74 86 117 129 162
Output
Nominal [kVA] (550 V) 46 53 72 86 108
Nominal [kVA] (575 V) 46 54 73 86 108
Nominal [kVA] (690 V) 55 65 87 103 129
Typical shaft output
[kW] (550 V) 30 37 45 55 75
[HP] (575 V) 40 50 60 75 100
[kW] (690 V) 37 45 55 75 90
Power loss Normal overload [W] 1458 1717 1913 2262 2662
Power loss High overload [W] 1355 1459 1721 1913 2264
Limits and Ranges
Warning Voltage Low DC Bus V 585 585 585 585 585
Alarm Voltage Low DC Bus V 553 553 553 553 553
Warning Voltage High DC Bus V 1109 1109 1109 1109 1109
Alarm Voltage High DC Bus V 1130 1130 1130 1130 1130
Brake On Voltage DC Bus V 1084 1084 1084 1084 1084
Brake On Voltage (Full Duty Cycle) DC Bus V 1099 1099 1099 1099 1099
SMPS Start Voltage DC Bus V 508 508 508 508 508
SMPS Stop Voltage DC Bus V 478 478 478 478 478
Overcurrent Warning VLT Out 256 256 256 256 256
Overcurrent Alarm (1.5 sec delay) VLT Out 256 256 256 256 256
Earth Fault Alarm VLT Out 23 27 37 43 54
Heatsink Over Temperature Degrees C 75 75 75 75 75
Mains Phase Warning (5 sec delay) DC Bus Ripple VAC 70 70 70 70 70
Mains Phase Alarm (25 sec delay) DC Bus Ripple VAC 70 70 70 70 70
Fan On Low Speed Temperature Degrees C 45 45 45 45 45
Fan On High Sped Temperature Degrees C 50 50 50 50 50
Fan Off Temperature Degrees C <30 <30 <30 <30 <30
Fan Voltage Low Speed Fan VAC 200 200 200 200 200
Fan Voltage High Speed Fan VAC 230 230 230 230 230
NA* use existing 525 - 600 V drive
