VLT® 7000 Booster
EMC test results (Emission, Immunity)
The following test results have been obtained using a system with a frequency converter (with options if relevant), a screened control cable, a control box with potentiometer, as well as a motor and motor cable.
Emission
Environment Industrial environment Housing, trades and light industries
VLT 7002- 7011/ 380- 460V
Basic standard EN 55011 Class A1 EN 55011 Class B EN 61800- 3
Setup
Motor cable
Conducted 150 kHz-
30 MHz
Radiated 30 MHz- 1 GHz
Conducted 150 kHz-
30 MHz
Radiated 30 MHz- 1 GHz
Conducted/ radiated 150
kHz- 30 MHz
300 m unscreened/ unarmoured Yes
1)
No No No Yes/ No
50 m br. screened/ armoured
(Bookstyle 20m )
Yes Yes Yes No Yes/ Yes
VLT 7000 Booster with RFI filter option
150m br. screened/ armoured Yes Yes No No Yes/ Yes
300 m unscreened/ unarmoured Yes No No No Yes/ No
50 m br. screened/ armoured Yes Yes Yes No Yes/ Yes
VLT7000BoosterwithRFI-filter
(+ LC- module)
150m br. screened/ armoured Yes Yes No No Yes/ Yes
Emission
Environment Industrial environment Housing, trades and light industries
VLT 7016- 7072 / 380- 460 V
Basic standard EN 55011 Class A1 EN 55011 Class B
Setup
Motor cable
Conducted 150 kHz-
30 MHz
Radiated 30 MHz- 1 GHz
Conducted 150 kHz-
30 MHz
Radiated 30 MHz- 1 GHz
300 unscreened/ unarmoured No No No No
VLT 7000 Booster w/ o RFI filter option
150 m br. screened/ armoured No Yes No No
300 m unscreened / unarmoured Yes
1)
No No No
50 m br. screened/ armoured Yes Yes Yes NoVLT 7000 Booster with RFI- module
150 m br. screened/ armoured Yes Yes No No
1) Depending on installation conditions
In order to minimise the conducted noise to the mains supply and the radiated noise from the frequency converter system, the motor cables should be as short as possible and the
screen ends should be made in accordance with the section on electrical installation.
MG.70.A1.02 - VLT is a registered Danfoss trademark
127
